(888) 312-8812 Login SignupQuick-Strut Suspension Strut and Coil Spring Assembly
| Compressed Length | 13.52 IN |
| Extended Length | 19.39 in |
| Travel Length | 5.87 in |
| Body Length | 13.13 IN |
| Gas Charged | Yes |
| Parts Pack(s) | P01113 |
| Mounting Hardware Included | YES |
| Compressed Length | 343.4 MM |
| Extended Length | 492.5 MM |
| Travel Length | 149.1 MM |
| Body Length | 333.5 MM |
| Includes Bump Stop | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Ride Height | No |
| Strut Mount(s) Included | Yes |
| Strut Mount Insulator(s) Included | Yes |
| Coil Spring Included | Yes |
| Coil Spring Insulator(s) Included | Yes |
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708801910 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801300 |
| UPC | 00048598188632 |
| VMRS Code | 016020006 |
| UNSPSC | 25172007 |
| Brand | Part Number |
|---|---|
| AutoZone | LS5390951B, LS3485642B |
| Duralast | LS5390951B, LS3485642B |
| FCS | 2345540 |
| FCS Auto Parts | 2345540 |
| Ford | 7A2Z18124D, 7A2Z18124DB, 7A2Z18124E, 7A2Z18124EB, 7A2Z18124F, 7A2Z18124FB, 7A2Z18125D, 7A2Z18125DB, 7A2Z18125E, 7A2Z18125EB, 7A2Z18125F, 7A2Z18125FB |
| GABRIEL | G57096 |
| GSP AUTO PARTS NORTH AMERICA INC | 811032 |
| Leacree | 501711249 |
| MasterPro Shocks and Struts | 33FD1181 |
| NAPA Shocks | 271125 |
| QBAutomotive | 819652 |
| Sensen | 92140903 |
| UNITY AUTOMOTIVE | 2-15140-001, 4-11870-15140-001, 4-11850-15140-001, 15140 |
