(888) 312-8812 Login SignupCONMET 10001201 ASSY PRESET TP TRLR HP10
MSRP: $681.40
$17449
Save $506.91
Limited availability at this price!
In Stock
Get it by Monday, Jun 29
CONMET 10001201 Part Description
Manufacturer
| Hub Assembly Data | |
| Hub Assembly | 10001201 |
| Aftermarket Assembly | 10082229 Compare |
| Status | Service Only (Check with ConMet customer service for a possible replacement) |
| Assembly Type | PreSet Hub Assembly |
| Axle Location | Trailer |
| Axle Name | TP |
| Axle-Specific Specification | Aluminum |
| Mounting | Hub Piloted - 10 Studs |
| ABS | No |
| ABS Characteristic | ABS Ready - Stamped |
| Wheel Stud Bolt Circle Diameter | 285.75 mm |
| Wheel Stud | 102292 |
| Wheel Stud Standout | 3.81" |
| Detailed On | 10005365 |
| Hub Rating | 12,500 LBS 5,670 kg |
| Hub Cap Bolt Circle Diameter | 6.750" |
| Drum Pilot Diameter | 8.78" |
| Bearing Set | _-stand |
| Fill Hole | 9/16Ó-18 UNF Ñ #6 SAE J1926 |
| Fill Plug | Yes |
| ABS Offset | 2.20" |
| Hub Offset | 1.42" |
| Weight | 49.3 LBS 22.4 kg |
| Machining | 10033029 |
| Machined Flange Thickness | 1.53" |
| Casting | 10033028 |
| Casting Material | A356.0-T61 Aluminum |
| Seal Vendor | Generic Premium |
| Bill of Materials Ñ 10001201 Ñ PreSet Hub Assembly | |||||
| Item | Description | Material | Qty | Unit | Type |
|---|---|---|---|---|---|
| 107483 | SHIPPING PLUG EXTRUSION | PLASTIC | 1 | EA | Shipping Plug Extrusion |
| 103623 | PINE-TREE CLIP | PLASTIC | 2 | EA | Pine Tree Clip |
| 10005404 | SHIPPING CAP | PLASTIC | 1 | EA | Shipping Cap |
| 10080666 | SEAL | PREMIUM WHEEL SEAL | 1 | EA | Seal |
| 104412 | BEARING SPACER | STEEL | 1 | EA | Bearing Spacer |
| 104156 | CONE, BEARING | 1/2-STAND; STEEL | 2 | EA | Bearing Cone |
| 10033073 | #6 OIL PORT PLUG (MAGNETIC) | MILD STEEL | 1 | EA | Port Plug |
| 102292 | STUD, WHEEL - PROP CL 10.9 | M22 X 1.5MM X 5.34 LG | 10 | EA | Wheel Stud |
| 104157 | CUP, BEARING | 1/2-STAND; STEEL | 2 | EA | Bearing Cup |
| 10033029 | HUB, MACHINED | 10033028 HUB, CAST ALUM | 1 | EA | Hub Machining |
| 10033028 | HUB, CASTING | A356-T6 ALUMINUM | 1 | EA | Hub Casting |
CONMET 10001201 Cross References
| Brand | Part Number |
|---|---|
| CM10001201 | |
| NAVISTAR | FLTHUBPALW |
CONMET 10001201 Customer Reviews
No reviews yet
Be the first to review this product!
CONMET 10001201 Manufacturer Information
ConMet® is the market leader in wheel hubs, aluminum castings, and plastic components for commercial vehicles. It traces back its roots to 1964 when it started as a part of Portland Freightliner, a subsidiary of Consolidated Freightways. More than 30 years later, it began its operation under Amsted Industries, a global manufacturer of components serving the vehicular, railroad, construction, and industrial markets. Headquartered in Vancouver, Washington, ConMet takes pride in its patented innovations, including PreSet®, PreSet Plus®, and TruTurn® product lines. It uses cutting-edge design technologies, such as Solidification Modeling and Finite Element Analysis, and it works hand-in-hand with OE manufacturers to provide highly engineered solutions that best meet the customers' needs.
