ACCURIDE RY984K - Gunite REAR 6 SPOKE WHEEL
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
ACCURIDE part description
California Proposition 65 Warning
California Proposition 65 Warning
Technical Specifications
| Aftermarket Status | Obsolete |
| OE Service Replacement | RY248K |
| Limitations | Replacement is machined to accept a Tone (Exciter) Ring for Anti-Lock brakes. |
| Aftermarket Replacement | RY248K |
| Limitations | Replacement is machined to accept a Tone (Exciter) Ring for Anti-Lock brakes. |
| Finished Weight | 130 |
| Special Information | Serviced by RY248K. |
| Spoke Wheel Capacity lbs | 11500 |
| Number of Spokes | 6 |
| Spoke Wheel Size | 22 |
| Rim Size | 8.0 Maximum |
| Axle Group | R28 |
| Outer Bearing Cup | 47620 |
| Outer Bearing Cone | 47679 |
| Inner Bearing Cup | HM516410 |
| Inner Bearing Cone | HM516449 |
| Bearing Cup Spacing | 4.94 |
| Drive StudHub Cap Bolt Circle | 7.5 |
| Drive StudHub Cap Hole Pattern | (6) .62-11 |
| No of Rim Studs | 6 |
| Rim Stud Size | 0.75 |
| No of DrumRotor Bolts | 6 |
| DrumRotor Bolt Size | 0.62 |
| Spoke Offset | -1.32 |
| DrumRotor Mount Offset | -0.88 |
| DrumRotor Pilot Diameter | 11 |
| DrumRotor Bolt Circle | 12.75 |
| Seal Bore Diameter | 6.25 |
| Overall Length | 10.06 |
| Spoke Length | 7.06 |
| Drum Bolt Part No | WP373 |
| DrumRotor Washer Part No | W889 |
| DrumRotor Locknut Part No | W888 |
| Drive Stud Part No | W1341 |
| Rim Stud Part No | W855 |
| Drive Nut Part No | WP37 |
| Rim Nut Part No | WP148 |
| Drive Lockwasher Part No | WP593-10 |
| Rim ClampSpacer Band Part Nos | W1138 | WP479 View Clamp View Band |
| Exciter Tone Ring Part Nos | View |
Accuride® is a proud manufacturer of durable and dependable wheels for commercial and passenger vehicles. It is committed to delivering only the highest quality products to OEMs and the aftermarket, with the Accuride Quality and Lean Manufacturing System (QLMS) in place at each of its ISO/IATF 16949SO-certified facilities. Although this brand is more popular for its aluminum and steel commercial vehicle wheels, it also offers some of the best brake drums, brake rotors, slack adjusters, and hub assemblies in the market today. All these components are designed and produced following the strictest standards for maximum performance, durability, and reliability.
