RAYBESTOS 681778 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2022-2013 Ford F-250 Super Duty Front, 2022-2013 Ford F-350 Super Duty Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 681778 Specifications
Product Attributes
| ABS Tone Ring Included | Yes |
| Bearings Included | Yes |
| Center Hole Diameter | 4.925 IN |
| Center Hole Diameter | 125.1 MM |
| Construction | Full Cast |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.433 IN |
| Discard Thickness | 36.4 MM |
| Grade Type | Regular |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.089 IN |
| Inside Diameter | 230.85 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 6.698 IN |
| Mounting Bolt Hole Circle Diameter | 170.15 MM |
| Mounting Bolt Hole Quantity | 8 |
| Nominal Thickness | 1.499 IN |
| Nominal Thickness | 38.05 MM |
| Outside Diameter | 14.291 IN |
| Outside Diameter | 363 MM |
| Overall Height | 4.556 IN |
| Overall Height | 115.75 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 8 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213156836 |
RAYBESTOS 681778 Cross References
| Brand | Part Number |
|---|---|
| AUTOXTRA | AX901298 |
| Advance Auto Parts | YH507783, YH507783P, G15630SD |
| AutoZone | 75027DG, 75027DL |
| Autoxtra | AX901298P |
| BRAKEBEST | 63271RGS, 681778, 681778FZN, 681778R |
| Brembo | 09.E303.20 |
| CENTRIC | 120.65140, 121.65140, 320.65140, 320.65140F, 120.6514, 120.65143, 121.65143 |
| Centric Parts | 120.65140, 121.65140, 320.65140, 320.65140F |
| DURA CORP | BR901298 |
| DuraGo | BR901298, BR901298-02 |
| Dynamic Friction Company | 600-54224 |
| FORD | DC3Z1102B, HC3Z1102A, HC3Z1102H |
| Ford | PC3Z1102A |
| MAGMA PRODUCTS | PSR205252 |
| MOTORCRAFT | BRRF374 |
| Motorcraft | BRRF200, BRRF310 |
| NEOTEK | 1071138GF |
| NEWTEK AUTOMOTIVE | R1298 |
| Newtek Automotive USA | R1298 |
| POWERSTOP | AR85169EVC |
| PowerStop | AR85169, AR85169SCR |
| Qualis | 42301 |
| UAP | 2901298, 901298, R65140 |
| WORLDPAC | 1407-507783, 1427-108028 |
| Wagner Brake | BD180712E |
| Winhere | 663271 |
RAYBESTOS 681778 Fits Vehicles
- Ford F-250 Super Duty (2012-2024)
- Ford F-350 Super Duty (2012-2024)
