(888) 312-8812 Login SignupMONROE 5697 OESpectrum Suspension Shock Absorber
Tap to view 5 more
MSRP: $83.75
$5399
Save $29.76
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
MONROE 5697 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5697 Specifications
Product Attributes
| Lower Mount Code | LS25 |
| Upper Mount Code | S7 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Body Diameter | 1.75 IN |
| Compressed Length | 19.01 IN |
| Extended Length | 28.13 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.7/16" Sleeve OAL |
| Parts Pack(s) | P01699 |
| Travel Length | 9.12 in |
| Upper Mount Type | Stem Mount - 1.1/8" Stem Length X M8 Thread Pitch |
| Compressed Length | 482.9 MM |
| Extended Length | 714.5 MM |
| Travel Length | 231.6 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Body Diameter | 44.4 MM |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS25 |
| Upper Mount Code | S7 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598158000 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5697 Cross References
| Brand | Part Number |
|---|---|
| FCS | DT346330, DT341979 |
| FCS AUTO PARTS | DT346330 |
| GABRIEL | G51983 |
| KYB | 553389, 343413, 553390 |
| KYB AMERICA LLC. | 343413 |
| MasterPro Shocks and Struts | MZ104 |
| Mazda | BBM228910C, BBM228910D, BBM228910F, BBM234700A, BBM234900A, BBM328910C, BBM328910D, BBM334700A, BBM334900A |
| Monroe Shocks & Struts | 210102 |
| NAPA Shocks | 5697, 94389, NS5697 |
| OEM | BBM228910C, BBM228910F, BBM328910C, BBM328910D, BBM228910D |
| SENSEN | 3212-0429 |
| Sensen | 32120429 |
| Top Quality | 785697 |
| Ultra Spring Seat | G51983 |
MONROE 5697 Fits Vehicles
- Mazda 3 (2010-2011)
