MSRP: $49.50
$1799
Limited availability at this price!
In Stock
Fuel Element
Cat, Cummins, Detroit Diesel, Mack Engs
Fuel Element
The Baldwin Fuel Water Separator Filter incorporates a compact configuration with one included grommet and an optional gasket, allowing flexible adaptation during installation. Its internal separation layout helps remove moisture before fuel reaches injection components, supporting cleaner combustion and helping reduce varnish-forming contaminants. The design is suited to equipment that transitions between varying humidity levels or fuel sources that may introduce sediment or water. The connection points allow straightforward alignment during replacement, and the form factor allows service in tight compartments where hose access is limited. This Baldwin PF7680 contributes to fuel-system stability through adaptable mounting options and moisture-control capability.
| Height | 7 1/32 |
| Fits | "Caterpillar, Cummins, Detroit Diesel, Mack Engines with Davco Housing" |
| Grommets | [1] Attached |
| Height (mm) | 178.6 |
| Inside Diameter 1 | 21/32 |
| O-Ring | "{ES3012}, {G445}" |
| Optional Gasket | {G717} (for Webb Housing) |
| Outside Diameter 1 | 3 3/4 |
| Outside Diameter 1 (mm) | 95.3 |
| Remark 2 | One End |
| Replaces | "Davco 380087; Detroit Diesel 23514049; Mack 301SD19A, 301SD19B" |
| Inside Diameter 1 (mm) | 16.7 |
| Application | Caterpillar, Cummins, Detroit Diesel, Mack Engines with Davco Housing |
| Gasket | Optional Gasket: G717 (for Webb Housing) |
| Inside Diameter | 21/32 (16.7) One End |
| Technology | Filtration |
| Micron Rating | 4 Nominal, 13 Absolute |
| Outside Diameter | 3 3/4 (95.3) |
| Product Type | Fuel/Water Separator Element |
| Length | 7 1/32 (178.6) |
| Division | Engine Mobile Aftermarket Division |
| Includes | Grommet: [1] Attached |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8421230000 |
| UPC | 00791440057036 |
| Brand | Part Number |
|---|---|
| FF5369W, 301SD19B, L3578FN | |
| ALLIANCE | ABPN10GFF5369W |
| BALDWIN FILTERS | PF7621, PF7620, PF7680 |
| BIG A FILTER | 95451, 95651 |
| CARQUEST | 86651, 86451 |
| CHAMPION LABORATORIES | L9721F, L3578FN |
| DAVCO | 380087, 301SD19D, 102185 |
| DAVCO MFG | 380087 |
| DETROIT DIESEL | 23514049 |
| DONALDSON | P550969, P550463, P176160, P550414 |
| FLEETGUARD | FF5369W, FS1029W, FS1029, FS1016, FS1005, FF5315, FF5314, FS19536W, FF5278 |
| FLEETRITE | FSR819536W, FFR85315, FFR85314, FFR85278, FSR81029W, FSR81029, FSR81016, FSR81005 |
| FRAM | CS7772B, CS8744A, CS7772A, C8662, C8017 |
| GM GENERAL MOTORS | 23514049 |
| GRAINGER | 2KXR8, 2FBD3 |
| HASTINGS | FF1095 |
| HASTINGS OLD NUMBER | FF1066, FF1065 |
| IHC INTERNATIONAL HARVESTER | 2503566C1, 2503565C1, 1696265C1 |
| JURA (HIFI) | SN40540 |
| KRALINATOR | FS651 |
| LUBER-FINER | L3578FN , L9721F, L7921F, L3578FN1, L3578F, L3578FN |
| MACK | 301SD19A, 301SD19B , 5839FS1029W, 301SD19C, 301SD19, 45MB411A, 3076CS7772B, 3076CS7772A |
| MCI-MOTOR COACH IND. | 9051272 |
| NAPA GOLD | 3651MP, 3651, 3451 |
| PREMIUM GUARD | DW30111 |
| PUROLATOR | F65273 |
| SANDVIK | 4521197 |
| TAMROCK | 4521197 |
| VOLVO | VOE85105574, 85105574, 3919762 |
| WEBB | 6732 |
| WIX | 533651XE, 33651MP, 33651, 33451 |
| WIX FILTERS | WIX FILTERS, 33651 |
