66450 by MONROE - SHOCK
Tap to view 3 more
66450 by MONROE - SHOCK
66450 by MONROE - SHOCK
66450 by MONROE - SHOCK

Monroe 66450 - SHOCK

Part Number
66450
Manufacturer
MONROE
Description

SHOCK

details

$58.49

In stock

limited availability at this price!

New! No hassle Return Policy details
Does not qualify towards free shipping promotion details
Orders placed over the weekend will ship the following business day
Get it by Thursday, Dec 11
Pay over 3-12 months with Affirm Logo. Learn more

MONROE part description

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES   -- Designed to handle the demands of high mileage and severe use class 3-6 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while 2-in. or 2-1/4-in. reserve tube holds more fluid to improve performance (when required)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (on most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration, and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

Product Attributes

Lower Mount Code LS28
Upper Mount Code LS43
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout No
Part Description Shock Absorber
Compressed Length 12.41 IN
Extended Length 19.87 in
Gas Charged Yes
Lower Mount Type Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.5/8" Sleeve OAL
Parts Pack(s) None
Travel Length 7.46 in
Upper Mount Type Loop Bushing and Sleeve Mount - 14MM Sleeve ID X 39.69MM Sleeve OAL
Compressed Length 315.2 MM
Extended Length 504.7 MM
Travel Length 189.5 MM
Shock Absorber Rod End Measuring Point Center of Loop
Shock Absorber Body End Measuring Point Center of Loop

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598147394
VMRS Code 016008003
UNSPSC 25172011

Part Interchanges

MONROE 66450 Cross Reference

We have 10 alternatives for the 66450 by MONROE:

Fits Vehicles

  • Freightliner Sprinter 2500 (2010-2018)
  • Mercedes-Benz Sprinter 2500 (2010-2018)
