MONROE 5654 Part Description
Manufacturer
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 5654 Specifications
Product Attributes
| Compressed Length | 16.19 IN |
| Compressed Length | 411.2 MM |
| Extended Length | 20.53 in |
| Extended Length | 521.5 MM |
| Travel Length | 4.34 in |
| Travel Length | 110.2 MM |
| Lower Mount Type | Clevis Bracket Mount |
| Lower Mount Type | Clevis |
| Lower Mount Code | CLEV |
| Upper Mount Type | Stem Mount - 2.1/4" Stem Length X 3/8"-24 Thread Pitch |
| Upper Mount Code | S34 |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Mounting Hole |
| Gas Charged | Yes |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | P01720 |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598115379 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5654 Cross References
| Brand | Part Number |
|---|---|
| 5654ST, GB5Z17682ZAPTM | |
| Duralast | TS3339852B |
| FCS | 346091, 346241 |
| FCS AUTO PARTS | 346091 |
| INFINITI | E62101ND5A, E6210JK01B, E6210JK50C, E6210JL00B, E6210JU40A, E6210JU50A |
| Infiniti | E61101ND5B, E61101ND5C, E61101NL0A, E6110CM40B, E6110JJ52A, E6110JK00B, E6110JK01B, E6110JK01C, E6110JK02A, E6110JK50A, E6110JK50B, E6110JK50C, E6110JK50D, E6110JL00C, E6110JU40A, E6110JU41A, E6110JU50B, E6110JU51B, E61111ND5B, E61111ND5C, E61111NL0A, E6111CM40B, E6111JJ52A, E6111JK00B, E6111JK01B, E6111JK01C, E6111JK02A, E6111JK50A, E6111JK50B, E6111JK50C, E6111JK50D, E6111JL00C, E6111JU40A, E6111JU41A, E6111JU50B, E6111JU51B, E6210CM40B, E6210CM40C, E6210JJ52A, E6210JK00C, E6210JK01A, E6210JK02A, E6210JK50A, E6210JK50B, E6210JU42A, E6210JU52A, E6A101A36A, E6A10JK01B, E6A111A36A, E6A11JK01B, E6B101A31B, E6B101A36A, E6B10JK01A |
| KYB | 349096, 349089 |
| KYB AMERICA LLC. | 349089 |
| MasterPro Shocks and Struts | IN104 |
| Monroe Shocks & Struts | 210077 |
| NAPA Shocks | 5654, 94387, NS5654 |
| OEM | E6210JK01B, E62101ND5A, E6210JL00B, E6210JU50A, E6210JU40A, E6210JK50C |
| SENSEN | 3213-0551 |
| Sensen | 32130551 |
| UNITY AUTOMOTIVE | 2-255090-001, 4-11413-255090-001, 4-11415-255090-001, 4-11405-255090-001, 4-11407-255090-001, 255090 |
MONROE 5654 Fits Vehicles
- INFINITI Q40 (2015)
- INFINITI G25 (2011-2012)
- INFINITI G37 (2009-2013)
- INFINITI G35 (2007-2008)
