MONROE 5657 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5657 Specifications
Product Attributes
| Lower Mount Code | LS31 |
| Upper Mount Code | LS26 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 10 IN |
| Extended Length | 14.79 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 2" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 4.46 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 38.1MM Sleeve OAL |
| Compressed Length | 254 MM |
| Extended Length | 375.7 MM |
| Travel Length | 113.3 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS31 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 38.1MM Sleeve OAL |
| Upper Mount Code | LS26 |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598115638 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5657 Cross References
| Brand | Part Number |
|---|---|
| 5657ST, GB5Z17682ZCPTM | |
| KYB | 554387 |
| KYB AMERICA LLC. | 554387 |
| Kia | 546502K100, 546502K800, 546502K820, 546502K950, 546502K960, 546602K100, 546602K800, 546602K820, 546602K950, 546602K960, 553002K100, 553002K800, 553002K820, 553002K950, 553002K960 |
| MasterPro Shocks and Struts | KA104 |
| Monroe Shocks & Struts | 210079 |
| NAPA Shocks | 5657, NS5657 |
| OEM | 553002K960, 553002K100, 553002K820, 553002K950, 553002K800 |
| SENSEN | 1213-0613 |
| Sensen | 12130613 |
| Top Quality | 785657 |
| UNITY AUTOMOTIVE | 2-259080-001, 259080 |
MONROE 5657 Fits Vehicles
- Kia Soul (2010-2013)
