(888) 312-8812 Login SignupDELPHI FG0843 Fuel Pump Module Assembly
MSRP: $631.76
$31199
Save $319.77
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 4
DELPHI FG0843 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG0843 Specifications
Product Attributes
| System Pressure | 58 psi |
| Fuel Level Sender Assembly Included | Yes |
| Item Grade | Standard Replacement |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Vapor Pressure Sensor | No |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 65 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 22 82 |
| Resistance Ohms Full | 990 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 12 68 |
| Average Flow Rating | 21 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 58 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TH |
| UPC | 00689604202098 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG0843 Cross References
| Brand | Part Number |
|---|---|
| Airtex | E7197M |
| AutoZone | DFG0843 |
| Bosch | 67754 |
| CONTINENTAL AG | FP22055S |
| Carquest | M2316402 |
| Carter | P76067M, P76225 |
| Chrysler | 5143579AI, 5143579AL, RL143579AK, 5143 579AJ, 5143 579AN, 5143 579AP, 5143 579AQ |
| DENSO | 953-3061 |
| DENSO Auto Parts | 953-3061 |
| EVO Driveline | AFS0928S, AFS1033P, RE1033P |
| Ford | 5143579AA, 5143579AB, 5143579AC, 5143579AD, 5143579AE, 5143579AF, 5143579AH, 5143579AI |
| GMB | 520-2380 |
| Mopar | 05143579AB, 05143579AC, 05143579AD, 05143579AH, 05143579AI |
| N/A | 5143579AJ, 5143579AN, USEP7197M, F3108A, C0490M, 4010544 |
| Precision Fuel | A33055 |
| Spectra Premium | SP7010M, SP1204 |
| TYC | 150139-A |
| URO | CY0516864 |
| VDO | FP22055S |
| Walbro | TU171 |
DELPHI FG0843 Fits Vehicles
- Jeep Commander (2006-2010)
- Jeep Grand Cherokee (2005-2010)
