WEATHERHEAD FD69-1002-08-08 - Hansen and Gromelle Coupling - Half Coupling FD69 Male
- Part Number
- FD69-1002-08-08
- Manufacturer
- WEATHERHEAD
- Description
-
Hansen and Gromelle Coupling - Half Coupling FD69 Male
details
$4449
MSRP: $83.31
Save: $38.82
In stock
limited availability at this price!
. Learn more
WEATHERHEAD part description
California Proposition 65 Warning
California Proposition 65 Warning
| A in | 2.34 |
| B in | 1.64 |
| Coupling Size | 8 |
| Coupling Type | Male |
| Description | Dimensions (Female NPT) - Steel |
| Family | FD69 Series |
| Fig. | 1 |
| Hex1 (in) | 1.12 |
| Max. Operating Pressure (Connected)- Hydraulic (ps | 10000 |
| Min. Burst Pressure- Connected (psi) | 40000 |
| Port/Tube Outside Diameter Size | 8 |
| Rated Flow (LPM) | 170 |
| Rated Flow (gpm) | 45 |
| Repair Kit-Part number (Buna-N) | FF10166 |
| Sub-Title | 10,000 psi Water Blast |
| Thread (P) | 41641 |
| Type | Female Pipe |
| Vacuum (Connected only ) (in./Hg) | 28 |
Eaton Weatherhead FD69 Series Coupling
With its bigger surface contact area, the Eaton Weatherhead FD69 Series coupling offers a long lifespan even when used in rugged high-pressure and water blast applications. It is meticulously designed by experts to deliver a high fluid flow rate and minimal pressure drop.
Features & Benefits
- Carbon steel construction delivers long-lasting durability
- High-quality plating ensures outstanding corrosion resistance
- Safety sleeve lock offers protection against accidental disconnection
- Comes with a smooth-bore “straight-through” design for maximum fluid flow
- Sturdy back-up ring stops O-ring extrusion
- 10,000 psi maximum operating pressure and 40,000 psi minimum burst pressure
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
