GATES 85468 Part Description
Manufacturer
Product Description
EFG6K Spiral Wire Hose - SAE 100R15
Features & Benefits
- Spiral-wire reinforcement supports pressure stability under severe hydraulic demand
- Abrasion-resistant cover helps extend hose life in harsh work areas
- Designed to handle high-impulse service in powerful equipment applications
- Meets SAE 100R15 requirements for demanding hydraulic system performance
Gates Hydraulic Hose
The Gates Hydraulic Hose handles extremely high-pressure hydraulic service in demanding equipment applications. This EFG6K spiral-wire hose meets SAE 100R15 requirements and delivers 6000 PSI constant pressure performance. Its MSHA-approved cover supports abrasion resistance for tough jobsite and mobile equipment use. The Gates 85468 hose is suited for hydrostatic transmissions and hydraulic systems that face repeated impulse loads.
GATES 85468 Specifications
Product Attributes
| Product Type | EFG6K Spiral Wire Hose - SAE 100R15 |
| Industrial Description | 12EFG6KX25FT |
| Type | Hydraulic Hose |
| Hose Pressure Description | Extremely High Pressure |
| Maximum Working Pressure | 6000 PS |
| Burst Pressure | 24000 PS |
| Temperature Rating | -40 Deg. F to +250 Deg. F (-40 Deg. C to +121 Deg. C) |
| Length | 25 FT |
| Dash Size | 12 |
| Inside Diameter | .75 IN |
| Outside Diameter | 1.24 IN |
| Bend Radius | 4.7 IN |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | Four Alternating Layers of Spiraled, High-Tensile Steel |
| Cover Material | Synthetic Rubber - Polychloroprene - Type A - Color Coded Layline |
| Cover Type | Type A - Flame & Oil Resistant |
| Cover Color | Black |
| Coupling Recommendation | GlobalSpiral, Stainless Steel S |
| SAE Standard | 100R15 |
| EN Standard | 856 4SP |
| ISO Standard | 3862 Type R15 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| Stock Status | S |
| UPC | 00072053505993 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
