(888) 312-8812 Login SignupCENTRIC 102.01140 C-Tek Semi-Metallic Brake Pads with Shims
Tap to view 2 more
$18.39
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 102.01140 Part Description
Manufacturer
Product Description
C-Tek Semi-Metallic Brake Pads with Shims
Features & Benefits
- Shimmed to eliminate noise and vibration. Formulated for reduced noise. Semi-Metallic compounds. Post cured for consistent performance throughout the service life of the brake pad. 100% Asbestos and Copper free formulas.
- C-TEK® brake pads are OE matched providing consistent stopping power
- C-TEK(R) brake pads are OE matched providing consistent stopping power
- OE Matched
- Vibration Damping Shims
- For optimal noise control over a wide temperature range
- OE Matched Slots and Chamfers
- Slots & chamfers match OE design, allowing for less noise, vibration, and harshness.
CENTRIC 102.01140 Specifications
Product Attributes
| Product Grade [cntrc] | Standard |
| Weight [cntrc] Lbs | 2.40 |
| Weight [cntrc] Kgs | 1.09 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hardware Kit Number [cntrc] | 117.42028 |
| Pad Wear Sensor Included | No |
| Friction Material Composition | Semi-Metallic |
| Mounting Hardware Included | No |
| Pad Shims Included | Yes |
| Friction Material Attachment | Integrally Molded |
| Pad Quantity | 4 |
| Prepared For Pad Wear Sensor | No |
| Outer Pad Height | 69.200 MM |
| Outer Pad Height | 2.724 IN |
| Inner Pad Height | 69.200 MM |
| Inner Pad Height | 2.724 in |
| Outer Pad Width | 3.059 IN |
| Outer Pad Width | 77.700 MM |
| Inner Pad Width | 77.700 MM |
| Inner Pad Width | 3.059 in |
| Outer Pad Overall Thickness | 15.500 MM |
| Outer Pad Overall Thickness | 0.610 in |
| Inner Pad Overall Thickness | 15.500 MM |
| Inner Pad Overall Thickness | 0.610 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305090 |
| UPC | 00805890057161 |
CENTRIC 102.01140 Cross References
| Brand | Part Number |
|---|---|
| MAGMA PRODUCTS | MXD114M |
| N/A | MS7047, MS795, ZX161, MX161, 0870522, 0870555, 0871033, 0871175, 0871177, 0871212, 0871213, 0871270, E107-0114-0, FDB340, D238, D244, D246, 7047D114, 7100D173, 7100D244, 7150D238, 7150D246, D161, D173, D57, 794D57, 795D161, 795D57, D114, PFM114, 2811401, E10701140, 69052940, 4106013E90, 4106013E91, 4106031E92, 4106031E93, 4106031E94, 4106031E96, 4106032E97, 4106031E98, 4106031E99, 4106011P26, 4106011P85, 4106011P88, 4106016C90, 4106031E90KE, 410609C025, 410609C026, 41060D4690, D106031E85, D106037G94, DA06011P93, DA06032E93, DA06032E94, D106032E92, DA06011P90, DA06031E86, 4106001W25, 4106001W26, 4106001W94, 4106018W25, 41060A0100, 41060A0125, 41060A1485, 41060A1486, 41060B9500, 41060B9501, 41060B9525, 41060B9526, 41060B9527, 41060B9574, 41060B9575, 41060B9594, 41060D8593, 41060E4100, 41060E4125, 41060N3000, 41060N3010, 41060N3025, 41060N3026, 41060N3027, 41060N3028, 41060N4400, 41060N4425, 41060N4426, 41060N4427, 41060N4428, 41060N8525, 41060N9625, 41060N9685, 41060N9694, 41060R1000, 41060R1025, 41060R5225, 41060R5700, 41060R5725, 41060R5727, 41060S0128, 41060S0129, 41060S0160, 41060S0425, 41060S0426, 41060S3426, 41060S3427, 41060S6025, 41060S6085, 41060S6086, 41060U3400, 41060U3425, 41060U3426, 41060U8725, 41060U8925, 41060V2790, 41060Y4125, 449120070, 0449120080, 0449120090, 0449120100, 0449120150, 0449122020, 0449122060, 0449122070, 0449122071, 0449122080, 0449122090, 0449122110, 0449122111, 0449122120, 0449122121, 0449130010, 0449130020, 0449130030, 0449130060, 0449135030, MKD114, MKD244, MKD246, MRD114, MRD244, SGD114, SGD246, SGD57A |
| RAYBESTOS | SGD114, MGD114C, PG-D114 |
CENTRIC 102.01140 Fits Vehicles
- Nissan 810 (1977-1980)
- Nissan 280Z (1975-1978)
- Nissan 200SX (1980-1983)
- Nissan 260Z (1974-1975)
- Nissan 240Z (1970-1973)
- Toyota Crown (1968-1972)
- Nissan 720 (1980-1982)
- Nissan 620 (1978-1979)
- Toyota Mark II (1972-1976)
- Toyota Pickup (1974-1983)
- Toyota Cressida (1978-1980)
- Toyota Corona (1972-1982)
