(888) 312-8812 Login SignupBENDIX K025365 Brake Chamber (S-Cam)
Tap to view 5 more
$7599
Limited availability at this price!
In Stock
Get it by Tuesday, Feb 17
BENDIX K025365 Part Description
Manufacturer
Product Description
Brake Chamber (S-Cam)
Features & Benefits
- A highly reliable air brake chamber (S-cam) that’s built to offer an extended lifespan at a competitive price
- Made using premium-quality materials to ensure superior durability
- Engineered in a state-of-the-art facility to meet the strictest quality standards
- Tested to ensure trouble-free installation and operation
Courtesy of Bendix – All rights reserved
Bendix TYP-24 Air Brake Chamber
The Bendix TYP-24 air brake chamber is a critical air brake component designed to convert the energy of air pressure into mechanical force to apply the brakes and stop the vehicle. This is made following a stringent manufacturing process to ensure each Bendix rotochamber provides maximum performance and guaranteed efficiency.
BENDIX K025365 Specifications
Product Attributes
| Gross Weight | 4.500 KG |
| Height | 234 MM |
| Length | 150 MM |
| Market Indicator | Aftermarket New |
| Net Weight | 4.500 KG |
| Related Part | Spare Part/Kit; 800919 |
| Width | 234 MM |
| Chamber Type / Size | T24 |
| Clamp Angle | 45Adeg |
| Clevis / Yoke Arm Bushing Pin Diameter | A~ .50 IN (A~ 12.7 MM) |
| Clevis / Yoke Arm Link Pin Diameter | Not applicable to this part |
| Clevis / Yoke Pin Spacing | Not applicable to this part |
| Clevis / Yoke Style | Threaded (Standard) |
| Maximum Operating Temperature | 175 AdegF (79 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting Stud Length | 1.50 IN (38.1 MM) |
| Port Angle | 270Adeg |
| Push Rod Length (to Yoke Pin Center when Applicable) [IN] | 9.76 in |
| Push Rod Thread / Style | 5/8-18 UNF-2A |
| Service Chamber Joint Type | Double Clamp Band |
| Service Port (11) - Center | 3/8-18 NPT (Plugged) |
| Service Port (11) - Side | 3/8-18 NPT |
| Stroke | 3.00 IN (76 MM) |
| Stud Spacing | 4.75 IN (120.7 MM) |
| Stud Thread Size | 5/8-11 UNC-2A |
| Weatherproof | No |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (HTS) | 8412310080 |
| UPC | 04068078223352 |
| VMRS Code | 013010034 |
BENDIX K025365 Cross References
BENDIX K025365 Customer Reviews
No reviews yet
Be the first to review this product!
BENDIX K025365 Manufacturer Information
A part of the Knorr-Bremse Group, Bendix® provides the automotive and truck parts industry with cutting-edge energy management solutions, active safety technologies, and air brake charging for tractors, buses, commercial vehicles, trailers, as well as medium- and heavy-duty trucks throughout North America. Headquartered in Elyria, Ohio, Bendix Commercial Vehicle Systems employs over 3,200 people who work hand in hand for the accomplishment of the brand's vision: "to become the leading worldwide supplier of active vehicle safety systems within the commercial vehicle industry." This brand takes pride in being the first to introduce many notable parts and technologies to the North American commercial vehicle market. Among these many firsts are the groundbreaking air brake system technologies such as air dryers, air compressors, and ABS. At Bendix, exceeding industry standards is a strict requirement.
