MONROE 65405 Magnum Rear Suspension Shock Absorber

★★★★★ (0)
Monroe 65405 Suspension Shock Absorber Magnum Rear Suspension Shock Absorber
MONROE
Tap to view 11 more
Monroe 65405 Suspension Shock Absorber Magnum Rear Suspension Shock Absorber

$80.49

Limited availability at this price!

In Stock

Get as soon as Thursday, Nov 19
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

MONROE 65405 Part Description

Manufacturer

MONROE

Product Description

Magnum Rear Suspension Shock Absorber

Features & Benefits

  • INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65405 Specifications

Product Attributes

Compressed Length13.13 IN
Compressed Length333.5 MM
Extended Length20.07 in
Extended Length509.8 MM
Travel Length6.02 in
Travel Length152.9 MM
Lower Mount TypeLoop Bushing Mount - 3/4" Bushing ID X 1.9/16" Bushing OAL
Lower Mount TypeLoop (Eyelet) Bushing
Lower Mount CodeL3
Upper Mount TypeLoop Bushing Mount - 3/4" Bushing ID X 1.9/16" Bushing OAL
Upper Mount CodeL3
Shock Absorber Rod End Measuring PointCenter of Loop
Shock Absorber Body End Measuring PointCenter of Loop
Gas ChargedYes
Mounting Hardware IncludedYes
Parts Pack(s)P01009
Body ColorBlack
Cylinder ColorBlack
ColorBlack
Cylinder FinishPainted
Dust Shield IncludedYes
Dust Shield MaterialMetal
Includes Bump StopNo
Internal Rebound BumperNo
Hydraulic LockoutYes
Grade TypePremium
Active or Passive SuspensionPassive
Adjustable CompressionNo
Adjustable ReboundNo
Adjustable Ride HeightNo
Part DescriptionShock Absorber

Additional Information

MSDS Sheet Number01170
Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708803000
Harmonized Tariff Code (Schedule B)8708800050
Harmonized Tariff Code (HTS)8708801600
UPC00048598173058
VMRS Code016008003
UNSPSC25172011

MONROE 65405 Cross References

BrandPart Number
65405MM, C71-6005, MAE65405
Alliance PartsABPN32O900033, ABPN32G900033
AutomannA85023
BULLDOG HD SHOCKSHD1215-0038
Bulldog HDHD12150038
CHEVROLET3919950
DAFACHF113
Dayton Parts44185023
FCSF347251
FOX COMMERCIAL TRUCK SHOCKS98031028
GABRIEL85023, 89415
GM3919950
General Motors3919950
HALDEXSA65405
INTERNATIONALAMS650405
KYB341622
KYB AMERICA LLC.341622
MACK650405
MERITORM85023, M89415
MONROE VINTAGE650405
Monroe Shocks & Struts650405
NAPA Shocks65405
NEWAY57365405
OEMACHF113
PACCAR PARTS665928
POWER10 PARTSSSA-89408, SSA-85023
PeterbiltACHF113
SACHS NORTH AMERICA316305
Sachs316305
VOLVO / WHITE / GMCSA5023, 3919950
Volvo GM Heavy Truck3919950, SA5023

MONROE 65405 Fits Vehicles

  • Volvo FE (1992-1998)
