(888) 312-8812 Login SignupMagnum Suspension Shock Absorber
| Lower Mount Code | S6 |
| Upper Mount Code | S6 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Internal Construction Type | Twin Tube |
| Adjustable Damping | No |
| Color | Black |
| Finish | Painted |
| Shock Absorber Bore Size | 1-3/4 IN |
| Foam Cell Design | No |
| Shaft Diameter | 18 MM |
| Compressed Length | 13.125 IN |
| Dust Shield Material | Metal |
| Extended Length | 21.625 in |
| Gas Charged | Yes |
| Lower Mount Type | Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch |
| Parts Pack(s) | (2) P01482 |
| Travel Length | 8.5 in |
| Upper Mount Type | Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch |
| Compressed Length | 333.4 MM |
| Extended Length | 549.3 MM |
| Travel Length | 215.9 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Base of Stem |
| Shock Absorber Bore Size | 44.5 MM |
| Shock Absorber Bore Size | 1.75 IN |
| Adjustable Damping | No |
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598170156 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
| Brand | Part Number |
|---|---|
| 65115MM, MAE65115 | |
| AUTOCAR LLC | 373013201 |
| CHEVROLET | 3919945, 22099889 |
| GABRIEL | 85027, 89418 |
| GM | 22099889, 3919945 |
| General Motors | 22099889, 3919945 |
| Gold Shock Absorber | 5001318, 5001354 |
| HALDEX | SA65115 |
| INTERNATIONAL | AMS700118, AMS650115 |
| KONI | 881509 |
| MACK | 20874147, 700118MT, 650115MT, 650115 |
| MERITOR | M89418, M85027 |
| MONROE VINTAGE | 650115 |
| Meritor | 728640 |
| Monroe Shocks & Struts | 650115 |
| NAPA Shocks | 65115 |
| NAVISTAR | AMS65115 |
| NEWAY | 57374078, 57365115 |
| Navistar | AMS650115, AMS700118 |
| OEM | 373013201 |
| PRT HD | 925274 |
| VOLVO / WHITE / GMC | 3919945 |
| Volvo | 373013201 |
| Volvo GM Heavy Truck | 3919945 |
