(888) 312-8812 Login SignupMONROE 58574 Load Adjusting Ensamble de Amortiguador y Muelle de Resorte Paquete de 2
Tap to view 11 more
MSRP: $294.49
$18549
Save $109.00
Limited availability at this price!
In Stock
Get it by Thursday, Jul 30
MONROE 58574 Part Description
Manufacturer
Features & Benefits
- REDUCES SAG UNDER LOAD -- Ideal for occasionally hauling or towing varying loads; heavy gauge, calibrated coil spring reduces sag when loaded up to 1,200 lbs. (capacity limited by suspension, tires and transmission; see owner's manual)
- EXCEPTIONAL HANDLING -- Tuned specifically for each application, full-displaced valving automatically adjusts to road extremes to provide ride consistency
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and PTFE-banded piston helps reduce friction between the piston and pressure tube to enhance responsiveness to changing road surfaces
- LONGER SERVICE LIFE -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear while heavy-duty nitrocarburized rod delivers long life
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
MONROE 58574 Specifications
Product Attributes
| Compressed Length | 339.7 MM |
| Compressed Length | 13.38 IN |
| Extended Length | 21.2 in |
| Extended Length | 539.8 MM |
| Travel Length | 200 MM |
| Travel Length | 7.875 in |
| Lower Mount Type | Loop Bushing and Cantilever Pin Mount - 1/2" Stud Diameter X 1 5/16" Stud Length (Center of Loop to Frame) |
| Lower Mount Code | L1/CP3 |
| Upper Mount Type | Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.7/8" Pin Length (Hole Center to Center) |
| Upper Mount Code | XP7 |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Shock Absorber Rod End Measuring Point | Center of Cross Pin |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Parts Pack(s) | P00576,P00941 |
| Part Description | Shock Absorber and Coil Spring Assembly |
| Damping Type | Oil |
| Grade Type | Premium |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598010049 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 58574 Cross References
| Brand | Part Number |
|---|---|
| 58574ST, FULTAD5812RGK | |
| Buick | 22003121, 22003254, 22046423, 22046424, 22046427, 22046428, 22064048, 22064049, 22064104, 22064105, 22064107, 22064179, 22064183, 22064298, 22064299, 22064309, 22064310, 22064311, 22064400, 22064401, 22064433, 22064434, 22064435, 22064436, 22064601, 22064603, 22064630, 22181553, 88945177, 88945188, 88945821, 88945844, 88946013, 88946032, 88946558, 88946562 |
| Cadillac | 22003254, 22046498, 22064046, 22064047, 22064105, 22064183, 22064311, 22064321, 22064322, 22064424, 22064425, 22064426, 22064501, 22064518, 22064601, 22065201, 22113666, 22113667, 22181553, 22181559, 88946032, 88946562 |
| Chevrolet | 22046423, 22046424, 22046426, 22046427, 22046428, 22046810, 22064040, 22064041, 22064042, 22064043, 22064044, 22064045, 22064100, 22064101, 22064264, 22064265, 22064298, 22064299, 22064400, 22064401, 22064412, 22064413, 22064421, 22064422, 22064433, 22064434, 22064435, 22064499, 22064600, 22064603, 22064618, 22064630, 22064856, 22140148, 22140213, 22181553, 22181559, 88945177, 88945188 |
| FCS | SC00040 |
| GABRIEL | 43060, 43049 |
| NAPA Shocks | 58574 |
| Oldsmobile | 22046424, 22046426, 22046427, 22046445, 22064040, 22064041, 22064298, 22064299, 22064400, 22064401, 4993745 |
| Pontiac | 12322219, 22046423, 22046424, 22046426, 22046427, 22064040, 22064041 |
MONROE 58574 Fits Vehicles
- Chevrolet Chevy II (1968)
- Buick Sportwagon (1970-1972)
- Pontiac Tempest (1964-1970)
- Buick Special (1964-1969)
- Pontiac Grand Safari (1977-1978)
- Pontiac Star Chief (1963-1964)
- Pontiac Ventura (1971-1974)
- Pontiac GTO (1964-1973)
- Oldsmobile F85 (1964-1972)
- Oldsmobile Cutlass (1964-1974)
- Oldsmobile 442 (1964-1971)
- Chevrolet Nova (1969-1973)
- Chevrolet Chevelle (1964-1977)
- Chevrolet Biscayne (1965-1972)
- Buick Skylark (1964-1972)
- Buick Centurion (1971-1973)
- Buick Apollo (1973)
- Pontiac Laurentian (1971-1974, 1976-1981)
- Pontiac Safari (1987-1989)
- Pontiac Parisienne (1971-1974, 1976-1986)
- Pontiac LeMans (1970-1977)
- Pontiac Grandville (1971-1975)
- Pontiac Grand Prix (1963-1977)
- Pontiac Grand LeMans (1975-1977)
- Pontiac Grand Am (1973-1975)
- Pontiac Catalina (1963-1981)
- Pontiac Bonneville (1963-1981)
- Oldsmobile Vista Cruiser (1973-1975)
- Oldsmobile Toronado (1971-1978)
- Oldsmobile Delta 88 (1971-1985)
- Oldsmobile Cutlass Supreme (1967-1977)
- Oldsmobile Cutlass Tiara (1976)
- Oldsmobile Cutlass Salon (1975-1977)
- Oldsmobile Custom Cruiser (1977-1992)
- Oldsmobile 98 (1971-1984)
- GMC Sprint (1971-1977)
- Chevrolet Monte Carlo (1970-1977)
- Chevrolet Malibu (1973-1983)
- Chevrolet Impala (1971-1985)
- Chevrolet El Camino (1964-1977)
- Chevrolet Caprice (1966-1996)
- Chevrolet Bel Air (1965-1975, 1981)
- Cadillac Brougham (1987-1992)
- Cadillac Fleetwood (1977-1986, 1993-1996)
- Cadillac DeVille (1977-1984)
- Cadillac Commercial Chassis (1983-1984, 1992-1996)
- Buick Roadmaster (1991-1996)
- Buick Riviera (1971-1978)
- Buick Regal (1973-1977)
- Buick LeSabre (1971-1990)
- Buick Estate Wagon (1977-1983)
- Buick Electra (1971-1989)
- Buick Century (1973-1977)
