(888) 312-8812 Login SignupMONROE 34761 Gas-Magnum Rear Suspension Shock Absorber
Tap to view 11 more
MSRP: $100.95
$4549
Save $55.46
Limited availability at this price!
In Stock
Get it by Thursday, Aug 13
MONROE 34761 Part Description
Manufacturer
Product Description
Gas-Magnum Rear Suspension Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 34761 Specifications
Product Attributes
| Compressed Length | 13.125 IN |
| Compressed Length | 333.4 MM |
| Extended Length | 21.75 in |
| Extended Length | 552.4 MM |
| Travel Length | 8.625 in |
| Travel Length | 219.1 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS26 |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Upper Mount Code | S4 |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | P01135 |
| Body Color | Yellow |
| Cylinder Color | Yellow |
| Color | Yellow |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598050014 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 34761 Cross References
| Brand | Part Number |
|---|---|
| 34761MM, MAE34761 | |
| AL-KO Xtreme | 813097 |
| BILSTEIN | 33176857 |
| BULLDOG HD SHOCKS | HD1214-0601 |
| Bulldog HD | HD12140601 |
| Duralast | TS3331402B |
| FCS | 341582 |
| FCS AUTO PARTS | 341582 |
| Ford | 3U2Z18125RA, 6C2Z18124A, 6C2Z18125A, 7C2Z18125D, 8C2Z18124A, 8C2Z18124B, 8C2Z18124C, 8C2Z18124D, 8C2Z18125A, 8C2Z18125B, 8C2Z18125C, 8C2Z18125D, F2UZ18124B, F2UZ18124D, F2UZ18125D, F4UZ18125C, F5UZ18124A, F5UZ18124B, F5UZ18125A, F7UZ18125AA, F7UZ18125AB, F8AZ18125BB |
| GABRIEL | G63623, 91773, 58623, 83178, 61646 |
| HALDEX | SA34761 |
| KONI | 88051043 |
| KYB | 344371, KG5498, KG6414, 565010 |
| KYB AMERICA LLC. | 344371, KG5498 |
| LTV | 58623 |
| MERITOR | MG60183 |
| MOTORCRAFT | ASH1136 |
| MasterPro Shocks and Struts | FD125 |
| NAPA Proformer | SH81828 |
| NAPA Shocks | 76761 |
| NAVISTAR | AMS34761 |
| OEM | 8C2Z18125A, 8C2Z18125D, 8C2Z18125B, 8C2Z18125C |
| PRT | 173582, 925067 |
| SACHS NORTH AMERICA | 30777 |
| Sachs | 30777 |
| Sensen | 12140178 |
| TRW | JGT4168S |
MONROE 34761 Fits Vehicles
- Ford F-450 Super Duty (2026)
- Ford E-150 Econoline (2008)
- Ford E-150 (2008-2014)
- Ford E-350 Super Duty (1999-2019, 2021-2026)
- Ford E-450 Econoline Super Duty (1999-2002)
- Ford E-350 Club Wagon (2002-2005)
- Ford E-350 Econoline Club Wagon (1992-2002)
- Ford E-350 Econoline (1992-2000)
- Ford E-250 (2003-2014)
- Ford E-250 Econoline (1992-2002)
- Ford E-450 Super Duty (2003-2019, 2021-2025)
- Ford Econoline Super Duty (1996-1999)
