MONROE 34521 Part Description
Manufacturer
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 34521 Specifications
Product Attributes
| Compressed Length | 16.5 IN |
| Compressed Length | 419.1 MM |
| Extended Length | 27.5 in |
| Extended Length | 698.5 MM |
| Travel Length | 11 in |
| Travel Length | 279.4 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS47 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
| Upper Mount Code | LS47 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Yellow |
| Cylinder Color | Yellow |
| Color | Yellow |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598050946 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 34521 Cross References
| Brand | Part Number |
|---|---|
| 34521MM, MAE34521 | |
| AUTOZONE | TS34-33362B |
| AutoZone | TS3433362B |
| Bilstein | 24025508 |
| Bulldog HD | HD12140851 |
| Chrysler | 04670441AB, 04670442AB, 4670414AB, 4670441AB, 4670442AB, 5168238AA, 5168251AA, 5168254AA, 5168267AA, 5168269AA, 5168281AA, 52113675AE, 52113712AF, 52122226AC, 52122227AD, 52122228AD, 52122233AA, 52122290AA, 68052096AA, 68066275AA, 68066280AB, 68066281AA, 68066283AA, 68066284AA, 68066296AA, 68066297AA, 68069937AA |
| Dodge | 04670441AB, 04670442AB, 4670414AB, 4670441AB, 4670442AB, 5086561AB, 5086561AC, 5086561AD, 5086561AF, 5086565AB, 5086565AC, 5086565AD, 5086565AE, 5086565AF, 5086566AB, 5086566AC, 5086587AB, 5086589AB, 5086590AC, 5086590AD, 5086590AE, 5086590AF, 5086591AC, 5086591AD, 5086591AE, 5086591AF, 5086591AG, 5086592AB, 5086594AC, 5086594AD, 5086594AF, 5086599AC, 5086599AF, 5086599AG, 5086600AB, 5114489AB, 5134155AA, 5134155AB, 5134155AC, 5134162AA, 5134162AB, 5134162AD, 5134163AA, 5134163AB, 5134163AD, 5139017AB, 5139160AB, 5139160AD, 5168238AA, 5170296AD, 5170297AD, 5170297AG, 5170298AD, 5170298AG, 5174300AD, 5174300AF, 5174300AH, 5174301AF, 5174301AG, 5174302AD, 5174302AG, 5174303AD, 5174303AG, 5174303AH, 5174304AD, 5174304AH, 5174305AD, 5174305AF, 5174305AH, 5174306AD, 5174306AE, 5174915AD, 5174915AF, 5174994AB, 5174995AB, 5174995AE, 5174996AB, 5174996AE, 5174997AB, 5174997AD, 5174998AB, 5174998AD, 5179653AA, 5179654AA, 5179654AB, 5179655AA, 5179655AB, 5179656AA, 5179656AB, 5179657AA, 5179657AB, 5189389AC, 5189996AA, 5189997AA, 52014560AA, 52110144AD, 52110144AE, 52110146AB, 52110146AC, 52110146AD, 52110146AE, 52113498AB, 52113498AC, 52113498AE, 52113499AA, 52113499AC, 52113499AD, 52113499AE, 52113675AC, 52113675AD, 52113675AE, 52113676AC, 52113676AD, 52113676AE, 52113677AB, 52113677AC, 52113677AE, 52113712AE, 52113712AF, 52121136AB, 52121304AC, 52121304AE, 52121356AB, 52121356AC, 52121356AD, 52121356AE, 52121458AB, 52121458AD, 52121483AD, 52121572AE, 52121611AC, 52121611AE, 52121612AC, 52121612AE, 52121613AD, 52121614AD, 52121614AE, 52121616AD, 52121616AE, 52121788AB, 52121788AC, 52121788AD, 52121788AE, 52121974AA, 52121974AB, 52121975AA, 52121975AB, 52122033AA, 52122033AB, 52122033AC, 52122035AA, 52122035AB, 52122035AC, 52122036AA, 52122036AB, 52122036AC, 52122080AA, 52122081AA, 52122225AA, 52122225AC, 52122226AA, 52122226AC, 52122227AB, 52122227AD, 52122228AD, 52122229AA, 52122229AC, 52122230AB, 52122230AD, 52122232AD, 52122233AA, 52122290AA, 52122293AB, 52122324AA, 52122501AD, 52122501AE, 52853695AB, 52853696AA, 52853700AA, 52853701AA, 52853703AA, 52853704AA, 5290608AC, 5290674AA, 55366628AD, 55366628AE, 55366629AB, 55366630AD, 55366630AE, 55366631AD, 55366631AE, 55366636AE, 55366637AD, 55366637AE, 55366991AB, 55366992AB, 55366993AB, 55366993AD, 55366993AF, 55366994AB, 55366994AE, 62113712AF, 68014969AB, 68019276AC, 68019277AA, 68019277AC, 68019278AA, 68019279AA, 68019280AA, 68019284AC, 68019286AC, 68019287AC, 68019288AA, 68019289AB, 68019290AA, 68019291AA, 68033450AA, 68033451AA, 68033452AA, 68033453AA, 68034252AA, 68034253AA, 68034254AA, 68047560AA, 68047700AA, 68052096AA, 68056263AA, 68056263AB, 68056266AA, 68056267AA, 68056268AD, 68056321AA, 68056322AB, 68056323AB, 68057363AC, 68057364AC, 68057365AB, 68057367AC, 68057368AA, 68057368AB, 68057369AB, 68057371AB, 68057372AC, 68057374AA, 68064241AB, 68066275AA, 68066280AB, 68066281AA, 68066283AA, 68066284AA, 68066296AA, 68066297AA, 68066298AA, 68066299AA, 68067325AA, 68067326AB, 68067327AA, 68067327AB, 68067328AB, 68067329AB, 68067330AA, 68067331AA, 68067332AB, 68067333AB, 68067335AB, 68068325AA, 68069739AA, 68069937AA |
| Duralast | TS3433362B |
| FCS | 342564, 342566, 342528, 346848 |
| FCS AUTO PARTS | 342564, 342566 |
| GABRIEL | G63971, 61716, G64013, 61710, 61709, G63970 |
| KYB | 344401, 565105, 5540020, 565132, 565104, 554360, 5650009, 3450016, 3450015, KG5196, 345062, KG54342, 344385 |
| KYB AMERICA LLC. | 344401 |
| MERITOR | MG61709 |
| MasterPro Shocks and Struts | DG110 |
| Monroe Shocks & Struts | 911222, 32401, 210443 |
| NAPA Proformer | SH81931 |
| NAPA Shocks | 76521 |
| NAVISTAR | AMS34521 |
| OEM | 68066296AA, 68066280AB, 68066297AA, 68069937AA, 5168269AA, 4670442AB, 68066284AA, 68066283AA, 68066281AA, 68052096AA, 52122227AD, 52122290AA, 52122228AD, 4670441AB, 5168267AA, 04670442AB, 52113712AF, 04670441AB, 5168251AA, 52122233AA, 5168281AA, 52122226AC, 68066275AA, 5168238AA, 5168254AA, 4670414AB, 52113675AE |
| PRT | 173802, 175441 |
| Ram | 04670441AB, 04670442AB, 4670414AB, 4670441AB, 4670442AB, 5168238AA, 5168251AA, 5168254AA, 5168267AA, 5168269AA, 5168281AA, 5189389AD, 52113675AE, 52113712AF, 52122226AC, 52122227AD, 52122228AD, 52122233AA, 52122290AA, 68014969AB, 68047560AB, 68047700AB, 68056266AA, 68056267AA, 68056268AD, 68056321AA, 68056322AB, 68056323AB, 68057363AC, 68057364AC, 68057365AB, 68057367AC, 68057368AB, 68057369AB, 68057371AB, 68057372AC, 68057374AA, 68064241AB, 68066275AA, 68066280AB, 68066281AA, 68066283AA, 68066284AA, 68066296AA, 68066297AA, 68066298AA, 68066299AA, 68067325AA, 68067326AB, 68067327AA, 68067327AB, 68067328AB, 68067329AB, 68067330AA, 68067331AA, 68067332AB, 68067333AA, 68067333AB, 68067335AB, 68069739AA, 68069937AA, 68139377AA, 68139380AA, 68139381AA, 68139383AA, 68139385AA, 68139388AA, 68139389AA, 68139390AA |
| Ram Trucks | 52122226AC, 5168251AA, 4670414AB, 4670442AB, 68066275AA, 52113675AE, 5168281AA, 68069937AA, 5168269AA, 68066296AA, 5168238AA, 52113712AF, 68066281AA, 52122228AD, 68066280AB, 4670441AB, 52122233AA, 5168254AA, 68066284AA, 52122227AD, 68066283AA, 5168267AA, 52122290AA, 68066297AA |
| Rancho | RS5269, RS55269 |
| SACHS NORTH AMERICA | 312480, 30877, 930013 |
| Sachs | 312480, 30877, 930013 |
| Sensen | 12140125 |
| TRW | JGT4238S |
| UNITY AUTOMOTIVE | 256200, 2-256200-001, 4-213060-256200-001 |
| Ultra Spring Seat | G63970 |
MONROE 34521 Fits Vehicles
- Ram 1500 (2012)
- Ram 3500 (2011-2012)
- Ram 2500 (2010-2013)
- Dodge Ram 1500 (2006-2008)
- Dodge Ram 3500 (2003-2010)
- Dodge Ram 2500 (2003-2010)
