(888) 312-8812 Login Signup| Compressed Length | 11.75 IN |
| Compressed Length | 298.5 MM |
| Extended Length | 15.875 in |
| Extended Length | 403.2 MM |
| Travel Length | 4.125 in |
| Travel Length | 104.8 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 2.7/16" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS77 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 2.7/16" Sleeve OAL |
| Upper Mount Code | LS77 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598021519 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
| Brand | Part Number |
|---|---|
| 32373MM, FT4Z5461203AB | |
| Chevrolet | 15032315, 22064224, 22064260, 22064333, 22064635, 22064638, 22064645, 22064658, 22064831, 22064832, 22064834, 22065237, 88945357, 88945370, 88945391, 88945885, 88945886, 88945961, 88946059, 88946581, 88946627 |
| GABRIEL | G63609, 61542, 58609, 81726 |
| GMC | 15032315, 22064224, 22064260, 22064333, 22064635, 22064638, 22064645, 22064658, 22064831, 22064832, 22064834, 22065237, 88945357, 88945370, 88945391, 88945885, 88945886, 88945961, 88946059, 88946581, 88946627 |
| KYB | 344266, KG5480, 565073, 565092, 565062, 565086 |
| NAPA Response | 94268 |
| Sensen | 12140129 |
