MGM BRAKES part description

General Description

Dry Bulk Chemicals

Features and Benefits

  • Tamper Resistant Design
  • Lighter Weight
  • 3 inch (76.2 mm) Long Stroke
  • Compact Size
  • Patented Integral Release Bolt Mechanism -Minimal Bolt Protrusion -Approx. 1.25 inch (31.8 mm) Protrusion On "Long Stroke" Models When Manually Released
  • Lower Hold Off Pressure (Less Air Consumption)
  • Non-Coil Clash Power Spring
  • Increased Corrosion Resistance -Steel head, Epoxy Coated

Technical Specifications

Stroke 3.00" (76.2 mm)
Weight lb (kg) Single 13.50 lb (6.1 kg)
B 7.94" (201.7 mm)
C 7.50" (190.5 mm)
D 6.76" (171.7 mm)
Inlets 3/8" - 18 NPTF (M16 x 1.5 - 6H)

Product Description

Piggyback Plus Kit

Features & Benefits

  • Tamper Resistant
  • Long Stroke
  • Compact
  • Integral Release Bolt
  • Epoxy Coated Return Spring/Steel Head
  • Non-Coil Clash Power Spring
  • Available w/1,749-2,450 lb of Push-Rod Brake Force @ 1.25” Stroke/Service
  • Available w/1,749-2,450 lb of Push-Rod Brake Force @ 1.25" Stroke/Service
  • Center Hole Shield

Product Attributes

Breather Tube Breather Tube
Chamber Type Piggyback Plus Kit
Diaphragm Diameter Rubber IN
Mounting Bolt Length N/A IN
Mounting Bolt Thread N/A
Port Size 3/8-18 NPTF
Spring Size 24
Service Size 24
Stroke 3.00 IN
UNIT Aftermarket

Additional Information

Country of Origin (Primary) US
21
VMRS Code 013004001
