(888) 312-8812 Login SignupGATES TR28743 Green Stripe Truck & Bus Series V-Belt
Tap to view 1 more
$52.69
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES TR28743 Part Description
Manufacturer
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
Allis-Chalmers, 8DA1290, , Fan
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES TR28743 Specifications
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | VA |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .775 in |
| Outside Circumference | 74.94 in |
| Effective Length | 74.36 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 20 mm |
| Outside Circumference | 1905 mm |
| Effective Length | 1889 mm |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4010343000 |
| Stock Status | N |
| UPC | 00072053274707 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES TR28743 Cross References
| Brand | Part Number |
|---|---|
| 86200218 | |
| <Unknown> | 138742, 4128530, 487654 |
| ACDelco | T28743 |
| Allis Chalmers | 169423, 4363869, 4367196, 4371885, 4373548, 4373760, 4616612, 4616613, 69423, DE106923, DE628693, DE63592, DE63869, DE638692, DE638693, DE67196 |
| BF Goodrich | 27747 |
| Bando | 7730, 7725 |
| CONTINENTAL AG | 28743 |
| Carquest | TR28743 |
| Caterpillar | 7M4002, 7M4003 |
| Cummins | 132237, 151428, 178572, S2511, S3173 |
| Dayco | 28740, 44215, 51728, 56237, 58305, 636M, 866 |
| Deutz-allis | 70169423, 74363869, 74371885, 74616612, 74616613 |
| Fleetrite | ZAH28740 |
| Freightliner Trucks | 412854 |
| GOODYEAR BELTS | 28743 |
| Gardner Denver | 13C181, 13C184 |
| General Motors | 43581, 5115940, 9043581 |
| Goodyear | 28743 |
| International Harvester (IHC) | 310357R11 |
| Komatsu | 0412102261 |
| Leroi | 4166, 4175 |
| MBL Three Stars | 28740 |
| Mack | 88GB172, 88GB330P196 |
| Metric | 20A1885 |
| Mitsuboshi | RECMF9730, RECMF9735 |
| Mopar | BH-284 |
| Murphy | MD10728, MD40275 |
| NAPA | 25-18880 |
| Oshkosh | SK811 |
| Wagner Electric | AD13750 |
| Waukesha | 199284, A199284 |
| White | 412853 |
