(888) 312-8812 Login SignupGATES G25645-1628 Female DIN 24 Cone Swivel - Light Series with O-Ring (MegaCrimp)
Tap to view 3 more
$14099
Limited availability at this price!
In Stock
Get it by Thursday, Aug 13
GATES G25645-1628 Part Description
Manufacturer
Product Description
Female DIN 24 Cone Swivel - Light Series with O-Ring (MegaCrimp)
Features & Benefits
- Robust "bite-the-wire" crimp
- Robust “bite-the-wire” crimp
- Tested to an industry-leading 1 million impulse cycles
- Simplifies inventory management
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance SAE Standard
- Popular thread styles also available with TuffCoat Xtreme plating for 583 percent better corrosion resistance than the SAE standard
GATES G25645-1628 Specifications
Product Attributes
| Termination | DIN |
| O-Ring Location | On Female w/Inverted Nose Seat |
| Seat Angle | 24 |
| DIN Series | Light |
| Gender | Female |
| Bent Tube Angle | Straight |
| Swivel | Yes |
| Coupling Description | MegaCrimp Female DIN 24 Cone Swivel - Light Series w/ O-Ring |
| Industrial Description | 16G-28FDLORX |
| Thread Size | M36X2.0 |
| Inside Diameter | 1 IN |
| Hydraulic Hose Recommendation | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
| Outside Diameter | 28 MM |
| Nut Hex Size | 41 MM |
| Cut-Off Length | 1.44 IN |
| Length | 3.21 IN |
| Seal Type | Mated Angle w/O-Ring |
| Inside Diameter | 25.4 MM |
| Cut-Off Length | 36.7 MM |
| Length | 81.6 MM |
Additional Information
| Country of Origin (Primary) | CZ |
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Stock Status | S |
| UPC | 00072053206104 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G25645-1628 Cross References
| Brand | Part Number |
|---|---|
| Aeroquip | 1A25DL16 |
| Caterpillar | 124-2210, 124-2240 |
| Dayco | 116178 |
| Goodyear | 14240-1636, B2-DLFX-1636, UC-DLFX-1636 |
| Kurt Hydraulics | F-DINLX-16-36 |
| N/A | 04032550, M21513-16-36 |
| NAPA | G25645-1628 |
| Parker | 1C343-28-16, 1CA43-28-16, 1CA71-28-16 |
| Weatherhead | 16U28C, 16Z28C, 16U-28C, 16Z-28C |
