GATES G25241-1010 Part Description
Manufacturer
Product Description
Female Flat-Face O-Ring Swivel - 90 Bent Tube (MegaCrimp)
Features & Benefits
- Robust "bite-the-wire" crimp
- Robust “bite-the-wire” crimp
- Tested to an industry-leading 1 million impulse cycles
- Simplifies inventory management
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance SAE Standard
- Popular thread styles also available with TuffCoat Xtreme plating for 583 percent better corrosion resistance than the SAE standard
GATES G25241-1010 Specifications
Product Attributes
| Coupling Description | MegaCrimp Female Flat-Face O-Ring Swivel - 90 Bent Tube |
| Industrial Description | 10G-10FFORX90L |
| Thread Size | 1-14 |
| Inside Diameter | .625 IN |
| Hydraulic Hose Recommendation | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
| Nut Hex Size | 30 MM |
| Drop Length | 2.76 IN |
| Cut-Off Length | 2.07 IN |
| Length | 3.55 IN |
| Seal Type | O-Ring |
| O-Ring Location | Flat Face O-Ring |
| Gender | Female |
| Bent Tube Angle | 90 |
| Swivel | Yes |
| Bulkhead | No |
| Inside Diameter | 15.9 MM |
| Drop Length | 70 MM |
| Cut-Off Length | 52.7 MM |
| Length | 90.2 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Country of Origin (Primary) | MX |
| Stock Status | S |
| UPC | 00072053206791 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G25241-1010 Cross References
| Brand | Part Number |
|---|---|
| Aeroquip | 1AA10FRC10 |
| Caterpillar | 124-2164 |
| Dayco | 108990, HY10-10OF90TL |
| Eaton | 10Z-A70 |
| Goodyear | 14720-1010, B2-OFFX90L-1010 |
| Kurt Hydraulics | FFX90L-10-10 |
| N/A | T2830-1016, 04032356, T2830-1019 |
| NAPA | G25241-1010 |
| Parker | 1J143-10-10, 1J1HY-10-10, 1J1HY-10-10-SM |
| Weatherhead | 10UA70, 10ZA70, 10M-A70, 10U-A70 |
