GATES G25240-1010 Part Description
Manufacturer
Product Description
Female Flat-Face O-Ring Swivel - 90 Bent Tube (MegaCrimp)
Features & Benefits
- Robust "bite-the-wire" crimp
- Robust “bite-the-wire” crimp
- Tested to an industry-leading 1 million impulse cycles
- Simplifies inventory management
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance SAE Standard
- Popular thread styles also available with TuffCoat Xtreme plating for 583 percent better corrosion resistance than the SAE standard
GATES G25240-1010 Specifications
Product Attributes
| Coupling Description | MegaCrimp Female Flat-Face O-Ring Swivel - 90 Bent Tube |
| Industrial Description | 10G-10FFORX90M |
| Thread Size | 1-14 |
| Inside Diameter | .625 IN |
| Hydraulic Hose Recommendation | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
| Nut Hex Size | 30 MM |
| Drop Length | 1.85 IN |
| Cut-Off Length | 2.18 IN |
| Length | 3.65 IN |
| Seal Type | O-Ring |
| O-Ring Location | Flat Face O-Ring |
| Gender | Female |
| Bent Tube Angle | 90 |
| Swivel | Yes |
| Bulkhead | No |
| Inside Diameter | 15.9 MM |
| Drop Length | 47 MM |
| Cut-Off Length | 55.3 MM |
| Length | 92.8 MM |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Stock Status | S |
| UPC | 00072053173505 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G25240-1010 Cross References
| Brand | Part Number |
|---|---|
| Aeroquip | 1AA10FRB10, FJ9893-1010S |
| Caterpillar | 124-2168 |
| Dayco | 108970 |
| Eaton | 10Z-J40, 1AA10FRB10.047 |
| Goodyear | 14715-1010, B2-OFFX90-1010, UC-OFFX90-1010 |
| Kurt Hydraulics | FFX90-10-10, FFX90M-10-10 |
| N/A | 04032354 |
| NAPA | G25240-1010 |
| Parker | 1J543-10-10 |
| Weatherhead | 10UJ40, 10ZJ40, 10U-J40 |
