GATES 85577 Part Description
Manufacturer
Product Description
GMV Global MegaVac Return Line & Suction Hose
Features & Benefits
- For use with GL Couplings [G43 Series] and MegaCrimp Couplings [G25 Series] (Use clamp over beaded nipple)
- Uses a helical spiral-wire to prevent hose collapse under suction
- Meets or exceeds requirements of SAE 100R4 and uses half the bend radius of SAE 100R4
- Meets marine ABS and DNV-GL with use of HeatGuard high temp sleeve and meets AS and USCG agency specifications
- Meets Flame Resistance Acceptance Designation MSHA 2G
- Temperature Range: -40 Deg. F to +275 Deg. F (-40 Deg. C to +135 Deg. C)
GATES 85577 Specifications
Product Attributes
| Product Type | GMV Global MegaVac Return Line & Suction Hose |
| Industrial Description | 12GMVX25FT |
| Type | Hydraulic Hose |
| Hose Pressure Description | Low Pressure |
| Maximum Working Pressure | 350 PS |
| Burst Pressure | 1400 PS |
| Temperature Rating | -40 Deg. F to +275 Deg. F (-40 Deg. C to +135 Deg. C) |
| Length | 25 FT |
| Dash Size | 12 |
| Inside Diameter | .75 IN |
| Outside Diameter | 1.22 IN |
| Bend Radius | 2.5 IN |
| Vacuum Rating | 25 INHG |
| Tube Description | Black, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | Double Spiral Braid w/ Helical Spiral-Wire |
| Cover Material | Synthetic Rubber - Neoprene - Type A |
| Cover Type | Type A - Flame, Oil & Abrasion Resistant |
| Cover Color | Black |
| Coupling Recommendation | GL, MegaCrimp |
| SAE Standard | 100R4 |
| EN Standard | N/A |
| ISO Standard | N/A |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| Country of Origin (Primary) | MX |
| UPC | 00072053449563 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
