Gates 3390 - Truflex FHP Low Horse-Power V-Belt
$1349
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Truflex FHP Low Horse-Power V-Belt
Application Summary
Goodall, 26WPS, , Drive
Features & Benefits
- Flex-bonded cords are strongly forged to the belt body, resulting in equal load distribution, resistance to fatigue and shock loads and the absorption of bending stress without cord deterioration
- Proprietary Flex-Weave cover is a patented fabric construction, providing extended protection to the belt core from oil, contaminants and heat for longer belt life
- Runs with smooth, quiet operation
- Meets RMA oil and heat-resistant standards and static conductivity requirements
- Available in 2L (0), 3L (1), 4L (2) and 5L (3) cross-sections
- Do not use on applications where FHP medium horsepower V-belts are recommended
Product Attributes
| Type | FHP Low Horse-Power V-Belt |
| Cross Section Designation | 5L |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .66 in |
| Outside Circumference | 39 in |
| Effective Length | 38.95 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 17 mm |
| Outside Circumference | 991 mm |
| Effective Length | 989 mm |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| UPC | 00072053007206 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
Part Interchanges
- Mopar B5L-390
- ACDelco 5L390
- Dayco 2M039
- Dayco 5L390
- BF Goodrich 2390
- General Electric K5705475AE8
- Goodall W00676
- CARQUEST 3390
- Silver Streak 75-839
- Silver Streak DB5L390
- American Lincoln 15908
- American Lincoln 20001043
- Auborn Construction 4518
- Browning Manufacturing 2360
- Excel Ind 782565
- Fiat 5553
- Frigidaire 635640
- John Deere LG58390
- John Deere TY4427
- Rotary Lifts 12-5166
- Manco 510025
- Goodyear 5L390
- Goodyear 75390
- Goodyear FB39
- NAPA Belts/Hose 5L390
- Gilmer 4390
- Grainger 5L390
- Mott P638
- Myers 5070A43
- Norge BD30E
- Oregon 75-839
- PIX A-5L390
- Power Lawnmower Part 109-177
- Reliance Electric 108095
- Ryan 548427
- Ryan M60
- U.S. Government 3030005284514
- U.S. Government MS392435L390
- Winchell 5539
- <Unknown> 1046058
- <Unknown> 105470
- <Unknown> 105598
- <Unknown> 105998
- <Unknown> 11087
- <Unknown> 12206
- <Unknown> 12802
- <Unknown> 135
- <Unknown> 15064
- <Unknown> 2039
- <Unknown> 286140
- <Unknown> 286141
- <Unknown> 286142
- <Unknown> 2MS4A150
- <Unknown> 3405510
- <Unknown> 344
- <Unknown> 36B
- <Unknown> 3E24
- <Unknown> 500438
- <Unknown> 519
- <Unknown> 630232
- <Unknown> 7008
- <Unknown> C4A10
- <Unknown> D50
- <Unknown> ER64210A
- <Unknown> R10825
- <Unknown> S622
- <Unknown> V2519
- L Series 5L390
- Metric 16R990
- X Series 10X386
- X Series 10X390
