(888) 312-8812 Login SignupFRAM PH7136 Spin-on Oil Filter
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
FRAM PH7136 Part Description
FRAM PH7136 Specifications
Product Attributes
| Height | 7.383 IN |
| Gasket Or Seal Included | Yes |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Filter Type | Spin-On Canister |
| Gasket Thickness | 0.250 IN |
| Housing Color | Orange |
| Non Slip Grip | No |
| Torque Nut | No |
| Gasket Inside Diameter | 2.460 IN |
| Gasket Outside Diameter | 2.813 IN |
| Drain Plug Included | No |
| Gasket Type | Base |
| Grade Type | Regular |
| Inlet Type | Threaded |
| Inside Thread Diameter | 1-12 IN |
| New Or Remanufactured | New |
| Outside Diameter | 4.250 IN |
| Reusable | No |
| Thread Size | Standard |
| Universal Or Specific Fit | Specific |
| Universal Or Specific Fit | Specific |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100423566 |
| UNSPSC | 15121501 |
FRAM PH7136 Cross References
| Brand | Part Number |
|---|---|
| AC-DELCO | PF1118, PF1257 |
| ACDelco | PF1118, PF1257 |
| ALLIANCE | ABP/N10G-LF3393, ABP/N10G-LF3455, ABP/N10G-LF702 |
| ATLAS-COPCO | 9710-1619 |
| Alliance Truck Parts | ABP/N10G-LF3393, ABP/N10G-LF3455, ABP/N10G-LF702 |
| BALDWIN | B129, B263, B309 |
| Baldwin | BK6596, BK6604, BK6611, BK6612, BK6614, BK6802, BK6830, BK6831 |
| Big A | 92747, 92808 |
| Carquest | 85747, 85808 |
| Coach Guard | T08-1069 |
| Donaldson | LFP553871, P550319, P550393, P553871, P559045, P559200, P559207, P559215, P559236 |
| Fleetguard | LF3393, LF3455, LF702, MK13103 |
| Fleetrite | LFR-8702, MKR-81421, MKR811267, MKR811268, MKR811418 |
| General Motors | 25012634 |
| Hastings | LF241, LF356, LF478 |
| International Harvester IHC | 1811953C1 |
| Kralinator | L140 |
| LUBER-FINER | 003 184 3301, LFP2244, LFP3871, LK151T, LK155I, LK185T, LK59T, LK98T |
| Mann-Filter | W1165/1, W1167/2 |
| Mercedes-Benz | 31841701 |
| Motorcraft | FL-773, FL-773FP |
| NAPA | 1808 |
| PREMIUM GUARD | HG50043 |
| Purolator | L40129, L49087 |
| Thermo-King | 12-3871-A, 12-5702A, 1388958, 1498166, 1680422, 1680787, 2630052, 720199, 720229 |
| WIX FILTERS | WIX FILTERS, 51747 |
| Wix | 51747, 51808 |
