FRAM PH3569 Part Description
Manufacturer
Product Description
FRAM, PH3569, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- Silicone anti-drain back valve helps ensure safe engine start up
Spin-on Oil Filter
FRAM PH3569 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 5.172 IN |
| Anti-Drain Back Valve | Yes |
| Bypass Relief Valve | Yes |
| Filter Type | Spin-On Canister |
| Gasket Thickness | 0.328 IN |
| Housing Color | Orange |
| Non Slip Grip | No |
| Torque Nut | No |
| Gasket Inside Diameter | 2.422 IN |
| Gasket Outside Diameter | 2.813 IN |
| Attachment Type | Spin-On |
| Bypass Relief Valve Setting | 19-37 PS |
| Gasket Type | Base |
| Grade | Advanced |
| Grade Type | Regular |
| Inlet Type | Threaded |
| Inside Thread Diameter | 3/4-16 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| Outside Diameter | 3.688 IN |
| Replacable Filter | Yes |
| Reusable | No |
| Thread Size | Standard |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100380999 |
| UNSPSC | 15121501 |
FRAM PH3569 Cross References
| Brand | Part Number |
|---|---|
| AC-DELCO | PF1093, PF960 |
| ACDelco | PF1093, PF1574, PF960 |
| AMSOIL | ASF15, EAO39 |
| ATLAS | M-53 |
| AUTOEDGE | AL3569 |
| AUTOPAR | FE222 |
| AUTOPRO | 2452 |
| AWARD | AOF-257 |
| Amsoil | EAO15 |
| Auto Extra | 61851191 |
| Autopar - Archived | FE222 |
| BALDWIN | B114 |
| Beck/Arnley | 041-0718, 041-8058, 041-8139, 041-8158 |
| Big A | 92190, 92191, 92452 |
| Bosch | 72174 |
| Canada Tire | 17-1882-6 |
| Car Care | IOF3569, OF3569 |
| Carquest | 85191, 85452, B257, R85191 |
| Carquest Premium Filters | 85191 |
| Casite Filters | CF1A |
| Cenex | CO2815 |
| Champ | PH2815 |
| Champion | OF25 |
| Champion Filters | OF25 |
| Crosland | 2049 |
| Cruisemaster | 225D |
| DENSO | 150-2067 |
| Defense Filters | DL3569 |
| Deutsch | D534 |
| Donaldson | P557780 |
| EXXON/MOBIL OIL | M1301A |
| Econo-lube | L30257 |
| FRAM Drive | FD3569 |
| FVP | LF492 |
| Facet Industrial | 3850 |
| Factory Motor Parts | R1452 |
| Filters Inc | OF3569 |
| Firestone | TF-3850, TF3850 |
| Flag | C-3569 |
| Fleetguard | LF3451, LF3580, LF3638 |
| Fleetrite | LFR-83451 |
| General Motors | 25011243 |
| Girling | F3715 |
| Gonher | GP3569 |
| Goodyear | 222-4521, L3850 |
| Grand Prix | PH2815 |
| Grease Monkey | GM30257, GM3850 |
| Group 7 | V257 |
| Gulf | GF-225D |
| Hastings | LF517, LF521, LF453, LF492 |
| Havoline | TFC-502 |
| IAPCO | A-0280-006, OF115, A-0280-001 |
| IPD | 12059, 4-1093 |
| ITM | 11-12100, 11-19813, 111-9813 |
| ITM Autoparts | 11-12100, 11-19813, 111-9813 |
| Installer Edge | AL3569 |
| International Parts Service | 4-1093 |
| Jiffy Lube | HL3569, JL257, L30257 |
| K Mart | K-38, MP-38 |
| Kendall | K13 |
| Knecht | AW56 |
| Kralinator | L130 |
| LUBER-FINER | LFP8452, PH2815 |
| Lee | LF-2815HP |
| Letourneau | MO2815 |
| Linde | 06-811-5561 |
| MAHLE | OC262, OC51, OC51OF, OC 262, OC 51, OC 51 OF |
| MANN-HUMMEL FILTERS | W940/25, W830/1, W840/2, W940/15N, W940/13, W94050 |
| MPA | 2010, 2012 |
| Mann-Filter | 6750458346, W 719/30, W840/2, W9.40/25, W930/7, W940/13, W940/25, W940/44 |
| Marathon | MO2815 |
| Master Parts | PH-2815 |
| MicroGard | MGL3569, MGL51191 |
| MicroGard Select | MSL51191 |
| Mighty Distributing System | M2901, M3569 |
| Minit-Lube | PH2815 |
| Mobil | MO257 |
| Mobil 1 | M1-301, M1-301A |
| Murphy | MD-438-14 |
| NAPA | 1191, 1333, 1452, 1452MP |
| Nissan | 15208-05D00, 15208-7F40A, 15208-W3401, 15208-W3403, AY100-NS009, AY100-NS010 |
| OE+ | OF-1360 |
| Parts Master | 61191 |
| Parts Plus | PH2815 |
| Pennzoil | PZ-22, PZ22 |
| Pentius | PLB3569 |
| Performax | PO-22 |
| Phillips 66 | PO83 |
| Pit Stop | PSL13 |
| Precision Tune | OF-111 |
| Premium Guard | PG257 |
| Pro-Gauge | PGO-257 |
| Pro-Tec | 184 |
| Pronto | PO-3569 |
| Purolator | L30257, L35331 |
| Quaker State | QS3569, QS3600 |
| STP | S3569 |
| STP Filters | S3569, S3569XL |
| Safety-Kleen | 153 |
| Security Filters | PH2815 |
| Service Pro | M257 |
| Shell - Archived | SH502 |
| Silverline | 21191 |
| Sunoco | O-10, O-22 |
| Trust | PH2815 |
| VIPER | 3569 |
| Valvoline | VO-24 |
| Vera | 10-00322, 10-01105, 10-01246, 10-50322 |
| Volkswagen | 068 115 561, 068 115 561B, 068 115 561E, 069 115 561 |
| Volvo | 1257492-7 |
| WIX FILTERS | WIX FILTERS, 51191 |
| Warner | PH2815 |
| Warner Filters | PH2815 |
| Western Auto | 74-5880-5 |
| Wix | 51191, 51333, 51452, 51452MP, 51647 |
FRAM PH3569 Fits Vehicles
- Volvo 265 (1980)
- Volvo 244 (1982-1984)
- Volvo 740 (1986)
- Volvo 245 (1982-1984)
- Volvo 264 (1980-1981)
- Suzuki Aerio (2002)
- Volkswagen Vanagon (1982-1984)
- Volkswagen Rabbit Pickup (1981-1983)
- Volkswagen Quantum (1982-1985)
- Audi 4000 (1982-1983)
- Volkswagen Rabbit (1977-1984)
- Audi A4 Quattro (1998-2005)
- Audi A4 (1998-2006)
- Volkswagen Passat (1993-2005)
- Volkswagen Golf (1985-1998)
- Volkswagen Jetta (1981-1998)
- Volkswagen Dasher (1979-1981)
- Audi 5000 (1979-1985)
