FRAM TG11665 Part Description
Manufacturer
Product Description
FRAM, TG11665, Oil Filter
Features & Benefits
- Proven protection for up to 15,000 miles (24,000 kilometers)
- Engineered for tough driving conditions, stop and go traffic, and hot and cold temperatures
- Synthetic blend media provides 99% dirt holding capacity
- Designed for use with synthetic or conventional motor oils
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
Cartridge Oil Filter
FRAM TG11665 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 6.127 IN |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Grade | Premium |
| Grade Type | Premium |
| Housing Color | NA |
| Inside Diameter Bottom | 0.914 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring Inside Diameter | 2.396 IN |
| O-ring Outside Diameter | 2.538 IN |
| O-ring Thickness | 0.142 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 1.990 in |
| Outer Diameter Top | 1.990 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 0.914 in |
| Torque Nut | No |
| Washable | No |
Additional Information
| Country of Origin (Primary) | BR |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100558930 |
| UNSPSC | 15121501 |
FRAM TG11665 Part Interchanges
| Brand | Part Number |
|---|---|
| Champ | P1009, P1009XL |
| Mopar | MO-349 |
| Hastings | LF697 |
| Promotive | PH6296 |
| Group 7 | V6296 |
| Ultra | XG11665 |
| Purolator | L36296 |
| Wix | WL10010, WL10010XP |
| LUBER-FINER | P1009 |
| Carquest | 94010 |
| Service Champ | CF6296 |
| Certified | CCH11665 |
| Chrysler | 68191349AA, 68191349AB, 68191349AC |
| Hengst | E721H |
| Warner | WP1009 |
| Defense Filters | DL11665 |
| NAPA | 100010 |
| FVP | G0010 |
| STP | S11665ML, S11665XL, S11665 |
| Carquest Standard Filters | R94010 |
| K&N | HP-7026, PS-7026 |
| Mighty Distributing System | M1009 |
| Pennzoil | PZ184 |
| ACDelco | PF600G |
| Quaker State | QS173BLK, QS184 |
| Firestone | P1009 |
| Baldwin | P9600 |
| Factory Motor Parts | G0010 |
| Champion | 55010T, 55101T, COC11665, PH500 |
| STP Filters | S11665, S11665ML, S11665XL |
| Mobil 1 | M1C-456A |
| MicroGard | MGL10010 |
| Performax | PO-184 |
| NAPA Gold Filters | 100010 |
| NAPA ProSelect Filters | 2100010 |
| MotoMaster | MCH11665 |
| Valvoline | VO-114 |
| Parts Master | WL610010, WL610010X |
| Premium Guard | PG6296, PG9925EX |
| Champion Filters | 55010T, 55101T, COC11665 |
| ECOGARD | S10040, X10040 |
| PUREPRO | PL6296 |
| NAPA Platinum Filters | 4100010 |
| Warner Filters | WP1009 |
| Purolator BOSS | PBL36296 |
| PureZone | 8-10010 |
| Purolator TECH | TL36296 |
| PurolatorONE | PL36296 |
| Tough Guard | TG11665 |
| FRAM Tough Guard | TG11665 |
| FRAM Ultra Synthetic | XG11665 |
| FRAM Core | COR11665ACC |
| FRAM Force | FF11665 |
| FRAM Titanium | FS11665 |
| FRAM Drive | FD11665 |
| FRAM Pro | FP11665BP |
| FRAM Synthetic Endurance | FE11665 |
FRAM TG11665 Fits Vehicles
- Suzuki Aerio (2002)
- Jeep Grand Cherokee WK (2022)
- Volkswagen Routan (2014)
- Jeep Grand Cherokee L (2021-2024)
- Chrysler Grand Caravan (2021-2024)
- Chrysler Voyager (2020-2024)
- Jeep Gladiator (2020-2024)
- Ram 1500 Classic (2019-2024)
- Chrysler Pacifica (2017-2024)
- Jeep Wrangler JK (2018)
- Ram ProMaster 2500 (2014-2024)
- Dodge Grand Caravan (2011-2020)
- Ram 1500 (2013-2025)
- Dodge Durango (2011-2024)
- Dodge Journey (2011-2019)
- Jeep Grand Cherokee (2011-2024)
- Jeep Cherokee (2014-2022)
- Dodge Avenger (2011-2014)
- Ram ProMaster 3500 (2014-2024)
- Ram ProMaster 1500 (2014-2024)
- Dodge Charger (2011-2023)
- Dodge Challenger (2011-2023)
- Chrysler Town & Country (2011-2016)
- Ram C/V (2012-2015)
- Chrysler 300 (2011-2023)
- Jeep Wrangler (2012-2024)
- Chrysler 200 (2011-2017)
