ICON 91816 15-20 F150 2WD 1.75-3" 2.5 VS RR COILOVER KIT

Name: Icon 91816 15-20 F150 2WD 1.75-3" 2.5 VS RR COILOVER KIT
SKU: 91816
Availability: OutOfStock

Tap to view 1 more

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

ICON 91816 Part Description

15-20 F150 2WD 1.75-3" 2.5 VS RR COILOVER KIT

Increased wheel travel over stock
Vehicle specific tuned front shocks for superior shock damping and control
External reservoir to attain cooler operating temperatures during extended off-road use
Improved ride quality over stock both on and off-road
Height-adjustable coilovers offer 1.75-2.63” of lift height adjustment
ICON engineered coil springs
6061 Aircraft grade aluminum CNC machined components
Corrosion resistant CAD plated shock body with 7/8" induction hardened, chrome plated shaft
High strength alloy CNC machined lower bar pIN
FK Rod End bearings for extended longevity and minimal deflection
100% Bolt-on - no cutting or welding necessary for installation

Factory Wheels & Tires Fitment: Yes

15-20 F150 2WD 1.75-3" 2.5 VS RR COILOVER KIT

Aap_uda_12	EA
Aap_uda_22	1
Aap_uda_4	55
Active or Passive Suspension	Passive
Add-on Part	191009 - ICON LONG 2.5 COIL WRAP W/LOGO (14.5-15.5)
Adjustable Compression	No
Adjustable Damping	NO
Adjustable Rebound	No
Adjustable Ride Height	Yes
Assembled	Yes
Body Diameter	2.5 in
California Prop 65 Warning	Yes
Coil Over Springs Included	Yes
Compressed Length	17.24 IN
Cylinder Color	Silver
Cylinder Finish	Cadmium Plated
Cylinder Material	Steel
Damping Type	Oil
Dust Shield Included	No
Extended Length	22.61 IN
10107	600 PPI
Gas Charged	yes
Grade Type	Performance
Includes Bump Stop	Yes
Internal Construction Type	Single Tube
Lower Mount Type	BAR PIN
Material	Steel
Maximum Lift	3 IN
Maximum Ride Height Raising Distance	3 IN
Minimum Lift	1.75 IN
OEM Wheels & Tires Fitment	Yes
Recommended Aftermarket Tires	33" x 11.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
Recommended Aftermarket Wheels	ICON Alloys - 20x9" w/ 5.625" Backspace / 16mm Offset
Remote Reservoir	Yes
Reservoir Style	Remote
Self-Leveling	No
Service Parts	252002 - UNIVERSAL SPANNER WRENCH (2.0/2.5/3.0)
Shaft Diameter	0.875 IN
Shock Absorber Body End Measuring Point	Top of Upper Mount Plate
Shock Absorber Rod End Measuring Point	Center of Eylet
Spring Color	Black
Spring Material	Steel
Spring Rate Type	Linear
Title	2015 F150 2WD 1.75-3" 2.5 VS RR COILOVER KIT
Travel Length	5.37 IN
Upper Mount Type	Mounting Plate
Valving Type	Digressive

Warranty Time	1
Warranty Time UOM	YR
Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8708807000
NAFTA Preference Criterion Code	C
UPC	00840103407074
