ICON 91000 04-08 F150 4WD 0-2.63" 2.5 VS IR COILOVER KIT

Name: Icon 91000 04-08 F150 4WD 0-2.63" 2.5 VS IR COILOVER KIT
SKU: 91000
Availability: OutOfStock

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

ICON 91000 Part Description

04-08 F150 4WD 0-2.63" 2.5 VS IR COILOVER KIT

Increased wheel travel and ride quality over stock
Vehicle specific tuned for superior shock damping and control
Adjustable 0-3" lift height
ICON engineered Eibach Springs
6061 Aircraft grade aluminum CNC machined components
Corrosion resistant CAD plated shock body with 7/8" induction hardened, chrome plated shaft
FK rod end bearings for extended longevity and minimal deflection
100% Bolt-on - no drilling,cutting or welding necessary for installation

Factory Wheels & Tires Fitment: Yes

04-08 F150 4WD 0-2.63" 2.5 VS IR COILOVER KIT

Aap_uda_12	EA
Aap_uda_22	1
Aap_uda_4	55
Active or Passive Suspension	Passive
Add-on Part	198001 - BILLET SPANNER WRENCH KIT
Adjustable Compression	No
Adjustable Damping	NO
Adjustable Rebound	No
Adjustable Ride Height	Yes
Assembled	Yes
Body Diameter	2.5 in
California Prop 65 Warning	Yes
Coil Over Springs Included	Yes
Compressed Length	17.85 IN
Cylinder Color	Silver
Cylinder Finish	Cadmium Plated
Cylinder Material	Steel
Damping Type	Oil
Dust Shield Included	No
Extended Length	23.21 IN
10107	600 PPI
Gas Charged	yes
Grade Type	Performance
Includes Bump Stop	Yes
Internal Construction Type	Single Tube
Lower Mount Type	Eyelet
Material	Steel
Maximum Lift	2.63 IN
Maximum Ride Height Raising Distance	2.63 IN
Minimum Lift	0 IN
OEM Wheels & Tires Fitment	Yes
Recommended Aftermarket Tires	33" x 11.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
Recommended Aftermarket Wheels	ICON Alloys - 17x8.5" w/ 5” Backspace / 6mm Offset
Remote Reservoir	NO
Reservoir Style	Internal
Self-Leveling	No
Service Parts	611019 - COILOVER HARDWARE KIT PAIR
Shaft Diameter	0.875 IN
Shock Absorber Body End Measuring Point	Top of Upper Mount Plate
Shock Absorber Rod End Measuring Point	Center of Eylet
Spring Color	Black
Spring Material	Steel
Spring Rate Type	Linear
Title	04-08 F150 4WD 0-2.63" 2.5 VS IR COILOVER KIT
Travel Length	5.37 IN
Upper Mount Type	Mounting Plate
Valving Type	Digressive

Warranty Time	1
Warranty Time UOM	YR
Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8708807000
NAFTA Preference Criterion Code	C
UPC	00840103406824
