(888) 312-8812 Login SignupCENTRIC 407.65004 Centric Premium Hub and Bearing Assembly; With Integral ABS
Tap to view 1 more
$598.18
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 407.65004 Part Description
Manufacturer
Product Description
Centric Premium Hub and Bearing Assembly; With Integral ABS
Features & Benefits
- 100% O.E. Quality Components. Premium seals protect internal components. Exacting Fit and Function. Complete cataloging; featuring the latest applications and covering from 1940 to 2017
- Double Row Ball or Taper Roller Bearings include integral encoder for ABS and TCS where applicable
- Gen 1
- Gen 2
- Double Row Ball or Taper Roller Bearing Assemblies include one mounting flange - includes integral encoder for ABS, TCS where applicable
- Gen 3
- Double Row Ball or Taper Roller Bearing Assemblies include 2 mounting flanges - includes integral ABS sensor where applicable
CENTRIC 407.65004 Specifications
Product Attributes
| Off-set [cntrc] Mm | 1.815 |
| Notes [cntrc] | Removable ABS wire , O-ring seal on inner pilot |
| Bolt Circle Diameter [cntrc] Mm | 170.000 |
| Mouting Thread Size [cntrc] Mm | 14.000 |
| Thread Pitch To Wheel Mounting [cntrc] Mm | 2.000 |
| Product Grade [cntrc] | Premium |
| Inner Mount Pilot [cntrc] Mm | 139.950 |
| Mounting Hole Qty [cntrc] | 4 |
| Bolt Circle Diameter [cntrc] In | 6.693 |
| Off-set [cntrc] In | 46.100 |
| Mounting Thread Pitch [cntrc] Mm | 1.500 |
| Wheel Stud Size | 14.000 MM |
| Wheel Pilot Diameter | 124.920 MM |
| Wheel Pilot Diameter | 4.918 IN |
| Brake Pilot Diameter | 128.930 MM |
| Brake Pilot Diameter | 5.076 IN |
| Wheel Stud Quantity | 6 |
| Wheel Studs Included | Yes |
| Flange Diameter | 7.987 IN |
| Flange Diameter | 202.950 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8482105016 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | US |
| UPC | 00805890645825 |
CENTRIC 407.65004 Cross References
| Brand | Part Number |
|---|---|
| 5C3Z 1102DAA, 5C3Z1102DAA, 6C3Z 1102DA, 6C3Z1102DA, 7C3Z 1102D, 7C3Z 1104D, 7C3Z1102D, 7C3Z1104D, AC3Z 1104C, AC3Z1104C | |
| BCA | WE61406HW, WE61406 |
| GMB | 7250009 |
| MEVOTECH | H515115 |
| N/A | SP940203, H515115, 515115, FW7115, WE61406, 6C3Z 1102DA, 6C3Z1102DA, AC3Z 1104C, AC3Z1104C, 7C3Z 1102D, 7C3Z 1104D, 7C3Z1102D, 7C3Z1104D, 5C3Z 1102DAA, 5C3Z1102DAA |
| NTN | WE61406 |
CENTRIC 407.65004 Fits Vehicles
- Ford F-450 Super Duty (2005-2010)
- Ford F-550 Super Duty (2005-2010)
