Centric 121.66074 - C-Tek Standard Brake Rotor
$11649
MSRP: $126.70
Save: $10.21
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Vane Style [cntrc] | Straight |
| Hat Id [cntrc] In | 8.835 |
| Product Grade [cntrc] | Standard |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 17.380 |
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Lbs | 38.300 |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] Mm | 224.400 |
| Discard Thickness | 1.516 IN |
| Discard Thickness | 38.500 MM |
| Nominal Thickness | 1.575 IN |
| Nominal Thickness | 40.000 MM |
| Overall Height | 102.000 MM |
| Overall Height | 4.016 IN |
| Outside Diameter | 355.000 MM |
| Outside Diameter | 13.976 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 127.100 MM |
| Center Hole Diameter | 5.004 IN |
| Mounting Bolt Hole Circle Diameter | 7.087 IN |
| Mounting Bolt Hole Circle Diameter | 180.000 MM |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 0.646 IN |
| Stud/Lug Hole Diameter | 16.400 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890702702 |
Part Interchanges
CENTRIC 121.66074 Cross Reference
We have 3 alternatives for the 121.66074 by CENTRIC:
Fits Vehicles
- Chevrolet Suburban 3500 HD (2016-2019)
- Chevrolet Silverado 3500 (2015-2018)
- Chevrolet Silverado 2500 (2014-2018)
- GMC Sierra 3500 HD (2011-2024)
- GMC Sierra 2500 HD (2011-2024)
- Chevrolet Silverado 3500 HD (2011-2024)
- Chevrolet Silverado 2500 HD (2011-2024)
