RAYBESTOS 580875 Brake Parts Inc Raybestos Specialty - Truck Disc Brake Rotor

★★★★★ (0)

MSRP: $289.75

$237.49

Save $52.26

Limited availability at this price!

In Stock

Get as soon as Wednesday, Nov 25
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

RAYBESTOS 580875 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Truck Brake Rotor

Application Summary

2024-2011 Chevrolet Silverado 2500 HD Front, 2024-2011 GMC Sierra 2500 HD Front, 2024-2011 Chevrolet Silverado 3500 HD Front, 2024-2011 GMC Sierra 3500 HD Front, 2019-2017 Chevrolet Suburban Front

Features & Benefits

  • OE Fit, Form, and Function
  • Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
  • Cooling Vanes
  • We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
  • We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring:Optimal coolingReduced fadeLess noiseIncreased pad life
  • Coating
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • SAE Standard for Tensile Strength
  • Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
  • Turned Finish
  • A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box

RAYBESTOS 580875 Specifications

Product Attributes

ABS Tone Ring IncludedNo
Center Hole Diameter5 IN
Center Hole Diameter127 MM
Conventional Or Drum-In-Hat Type RotorConventional
Directional or Non-Directional Brake SurfaceNon-Directional
Discard Thickness1.516 IN
Discard Thickness38.5 MM
Harmonize Code8708.30.5030
Inside Diameter9.961 IN
Inside Diameter253 MM
MaterialCast Iron
Mounting Bolt Hole Circle Diameter7.087 IN
Mounting Bolt Hole Circle Diameter180 MM
Mounting Bolt Hole Diameter0.636 IN
Mounting Bolt Hole Diameter16.15 MM
Mounting Bolt Hole Quantity8
Nominal Thickness1.575 IN
Nominal Thickness40 MM
Outside Diameter13.976 IN
Outside Diameter355 MM
Overall Height4.028 IN
Overall Height102.3 MM
Salability RestrictionsNo
Solid Or Vented Type RotorVented
Stud/Lug Hole Quantity8
Surface TypeSmooth
UNSPSC Code25171715

Additional Information

Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708309990
Harmonized Tariff Code (HTS)8708305030
UPC00829352841129

RAYBESTOS 580875 Cross References

BrandPart Number
ACDELCO177-1277
ADVANCE AUTO PARTSG12479SD, YH317206, YH317206C, YH317206P
AUTOPARTSOURCE493129
AUTOXTRAAX901026
AUTOZONE41268, 41268DG, 72020, 72020DG
Advance Auto PartsG09466SD
AutoZone72020SD
AutoxtraAX901026P
BENDIXPRT6074
BRAKEBEST580875, 580875FZN, 580875PER, 580875R
Brembo09.C751.10, 09.C751.21
CENTRIC120.66074, 120.66074CRY, 121.66074, 126.66074CSL, 126.66074CSR, 126.66074SL, 126.66074SR, 127.66074L, 127.66074R, 227.66074L, 227.66074R, 320.66074
Centric Parts120.66074, 120.66074CRY, 121.66074, 126.66074CSL, 126.66074CSR, 126.66074SL, 126.66074SR, 127.66074L, 127.66074R, 227.66074L, 227.66074R, 320.66074
Chevrolet13557896
DURA CORPBR55191, BR901026, BR901026-02
DuraGo901026, BR901026
Dynamic Friction Company604-48059
GM13512705, 13529518, 22752762, 23118117, 25807428, 84261376
GMC13557896
General Motors13512705, 13529518, 22752762, 23118117, 25807428, 84261376
MAGMA PRODUCTSPSR225260
MONROE BRAKESBD180441
NEOTEK1072088GF
NEWTEK AUTOMOTIVE55191
Newtek Automotive USA55191
OmnicraftQBRR114
POWERSTOPAR82153EVC
PROMAX14-55191
PRONTOBR901026
Parts Master901026
Qualis41268
TopNotchTN580875GEO
UAPR66074
WABCOPS901026
WABCO - ArchivedPS901026
WINHERE6621266
WORLDPAC1407-317206, 1427-523946
Wagner BrakeBD180844E, BD180441

RAYBESTOS 580875 Fits Vehicles

  • Chevrolet Silverado 2500 (2014-2018)
  • Chevrolet Silverado 2500 HD (2011-2025)
  • Chevrolet Silverado 3500 (2015-2018)
  • Chevrolet Silverado 3500 HD (2011-2025)
  • Chevrolet Suburban (2017-2019)
  • Chevrolet Suburban 3500 HD (2016-2019)
  • GMC Sierra 2500 HD (2011-2025)
  • GMC Sierra 3500 HD (2011-2025)
