(888) 312-8812 Login SignupRAYBESTOS PGD786AM Brake Parts Inc Raybestos Element3 Metallic Disc Brake Pad Set
$26049
Limited availability at this price!
In Stock
Get as soon as Wednesday, Oct 7
RAYBESTOS PGD786AM Part Description
Manufacturer
Product Description
Raybestos Element3 Metallic Brake Pad Set
Application Summary
2018-2003 Freightliner M2 106 Front, 2018-2003 Freightliner M2 106 Rear, 2009-2002 International 4300 Front, 2009-2002 International 4300 Rear, 2018-2005 Freightliner B2 Front, 2018-2005 Freightliner B2 Rear, 2022-2021 Ford F53 Rear
Features & Benefits
- Metallic friction material provides the working surfaces against the rotor
- Includes mounting hardware with the complete brake pad set
- Slots and chamfers shape the pad edges for the caliper package
- Restores fresh friction surfaces while the caliper and rotor remain
Raybestos Element3 Disc Brake Pad Set
Refresh the rotor-contact surfaces with the Raybestos Element3 Disc Brake Pad Set, supplied with metallic friction pads and the related mounting hardware. Slots and chamfers are formed into the pads, giving the set the edge treatment used by this Element3 design rather than a plain rectangular friction block. The friction pieces and installation hardware come together in one set. Slots, chamfers, fresh friction material, and companion hardware included with the Raybestos Brakes PGD786AM are supplied together for the rotor-contact surfaces.
RAYBESTOS PGD786AM Specifications
Product Attributes
| Chamfered Edges | Yes |
| FMSI Number | D786A-L7655 |
| Friction Material Attachment | Integrally Molded |
| Friction Material Composition | Metallic |
| Friction Material Slot Type | Slotted |
| Inner Pad Height | 3.350 in |
| Inner Pad Overall Thickness | 1.055 IN |
| Inner Pad Width | 9.610 in |
| Mounting Hardware Included | Yes |
| Outer Pad Height | 3.350 IN |
| Outer Pad Overall Thickness | 1.055 in |
| Outer Pad Width | 9.610 IN |
| Pad Shims Included | No |
| Pad Wear Sensor Attached | No |
| Pad Wear Sensor Included | No |
| Slotted | Yes |
Additional Information
| Country of Origin (Primary) | MX |
| Canadian Harmonizing Tariff Code | 8708301900 |
| Harmonized Tariff Code (HTS) | 8708305040 |
| UPC | 00747730521329 |
RAYBESTOS PGD786AM Cross References
| Brand | Part Number |
|---|---|
| 102.07861, 8.48341E+11 | |
| ABEX | SD786A |
| Abex Friction Products | SD786A |
| Advance Auto Parts | FLD786A, PMD786AH |
| American Remanufactured | 64-D786A |
| AutoZone | D786ASD |
| Autospecialty | 26-786A-01 |
| Bendix | MKD786 |
| Bosch | BHD786A |
| BrakeBest | MKD786A |
| CENTRIC | 102.07861 |
| Centric Parts | 102.07861, 104.07861, 106.07861, 300.07861 |
| Euclid | E-D786-S, E-D786A-M, E-D786A-S, E-D786A-V, E-D786S |
| Fleetrite | FLTH786, FLTH786A |
| Ford | 6C4Z2001AA, 8C4Z2001A, 8U9Z2001AB, LU9Z2001F, 4C4Z2001MA, 6C4Z2001BA |
| Formula Blue Hydraulic Brake Parts | E10707861, E10907860, E11107861 |
| International Harvester (IHC) | 2501841C91, ASL02040J2677 |
| International Harvester IHC | 2501841C93 |
| Inwood Automotive Products | TXD786A |
| KEM | PXD786A |
| MAGMA PRODUCTS | MXD786AM |
| Meritor | MD786A, MD786AM, MVD786A |
| Monroe Brakes | DX786A |
| Morse | MKD786A |
| Performance Friction | 0786.11, 0786.13, 0786.21, 786A4, 786AZ |
| PowerStop | Z36-786A |
| WAGNER | SX786A |
| Wagner Brake | FD786A, MD786A, SX786A |
RAYBESTOS PGD786AM Fits Vehicles
- Freightliner B2 (2005-2018)
- Freightliner Business Class M2 (2004-2012)
- Freightliner FS65 (1999-2008)
- Freightliner M2 (2005-2018)
- Freightliner M2 100 (2003-2010)
- Freightliner M2 106 (2003-2018)
- Freightliner M2 112 (2003-2018)
- Freightliner M2 T (2006-2010)
- Freightliner MB Line (2007-2022)
- Freightliner MC Line (2001, 2005-2018)
- Freightliner MCL (2011, 2014)
- Freightliner MT35 (2006-2009)
- Freightliner MT45 (2006-2021)
- Freightliner MT55 (2004-2019)
- Freightliner S2 (2007-2009, 2011)
- Freightliner S2C (2013-2022)
- Freightliner S2G (2014-2022)
- International 1652SC (1998-2005)
- International 3000 (1998-2002)
- International 3000FE (1998-1999)
- International 3000IC (2000-2002)
- International 3000RE (1996-2000, 2002, 2005)
- International 3200 (2002-2009)
- International 3300 (2005-2009)
- International 3400 (1998-2002)
- International 3600 (1998-1999, 2001-2002)
- International 3800 (1998-2004)
- International 4100 (2006-2009)
- International 4100 SBA (2006-2008)
- International 4200 (2002-2009)
- International 4200LP (2003-2008)
- International 4300 (2002-2009)
- International 4300LP (2002-2009)
- International 4400 (2002-2009)
- International 4400LP (2002-2009)
- International 4700 (1998-2005, 2008)
- International 4700LP (1998-2002)
- International 4700LPX (1998-2002)
- International 4800 (1998-2003)
- International 4900 (1998-2005)
- International CXT (2006-2007)
- Kenworth K300 (2000-2005)
- Kenworth T170 (2008-2018)
- Kenworth T270 (2008-2018)
- Kenworth T300 (2000-2008)
- Kenworth T370 (2008-2018)
- Peterbilt 325 (2008-2012)
- Peterbilt 330 (2008-2012)
- Peterbilt 335 (2008-2010)
- Peterbilt 337 (2010-2012)
- Blue Bird TC1000 (1998-2000)
- Blue Bird TC2000 (1998-2004)
- Fleetwood Bounder (2010, 2017-2019, 2021-2022)
- Fleetwood Bounder Anniversary Edition (2021)
- Fleetwood Bounder Classic (2013)
- Fleetwood Fortis (2021)
- Fleetwood Southwind (2018-2020)
- Ford F-53 Motorhome Chassis (2008-2009, 2011-2022)
- Ford F-59 Commercial Stripped Chassis (2011-2020)
- Ford F-650 (2004-2008)
- Ford F-750 (2004-2008)
- Ford F59 (2021)
- Forest River Georgetown GT7 (2020-2022)
- IC Corporation BE Commercial Bus (2008)
- IC Corporation BE School Bus (2008-2009)
- IC Corporation CE Commercial (2003-2008)
- IC Corporation CE Integrated (2005-2009)
- IC Corporation CE School Bus (2003-2004)
- IC Corporation HC Integrated Commercial (2007-2009)
- IC Corporation RE Commercial (2003-2009)
- IC Corporation RE Integrated (2005)
- IC Corporation RE School Bus (2003-2009)
- Itasca Suncruiser (2013-2016)
- Sterling Truck Acterra (2003-2008)
- Sterling Truck Acterra 5500 (2001-2007)
- Sterling Truck Acterra 6500 (2001-2007)
- Sterling Truck Acterra 7500 (2001-2007)
- Sterling Truck L7500 (2002-2006)
- Winnebago Adventurer (2013-2017)
- Winnebago Suncruiser (2016)
- Workhorse LF72 (2005-2009)
