(888) 312-8812 Login SignupBENDIX 800970 Foot Brake Valve
Tap to view 9 more
$71449
3 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
BENDIX 800970 Part Description
Manufacturer
Product Description
Foot Brake Valve
Features & Benefits
- Service-brake control starts at the driver-operated foot valve position
- Responds to pedal movement with graduated pneumatic brake delivery
- Complete valve assembly replaces the primary pedal-control component
- Routes the driver’s brake command into the service air system
Bendix Air Brake Foot Valve
For service at the driver-control point, the Bendix Air Brake Foot Valve provides the complete foot-operated assembly that begins a normal service-brake application. Pedal movement is translated directly into graduated pneumatic pressure, giving the driver a mechanical-to-air connection that changes output as more braking is requested. The Bendix 800970 carries that command into the primary control stage before relay valves distribute air farther through the system. This makes the assembly the right service focus when the problem is at pedal-operated pressure control rather than at a downstream delivery component.
BENDIX 800970 Specifications
Product Attributes
| Delivery (21) Port 1 | Cored Closed |
| Delivery (21) Port 2 | Cored Closed |
| Delivery (21) Port 3 | Open Port |
| Delivery (22) Port 1 | Cored Closed |
| Delivery (22) Port 2 | Cored Closed |
| Delivery (22) Port 3 | Open Port |
| Differential Pressure | 3.0 PSI |
| Exhaust Port | Dust Shield |
| Graduation Spring Style | Rubber |
| Initial Pedal Angle | Not applicable to this part |
| Manifold Included | Yes |
| Market Indicator | Aftermarket New |
| Maximum Operating Temperature | 200 AdegF (93 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting (Valve Body) | 5/16-18 UNC-3B (3x) |
| Mounting (Vehicle) | A~ .420 IN (4x) |
| Mounting Nuts / Washers Included | Not applicable to this part |
| Mounting Plate Included | Yes |
| Mounting Stud Length | Not applicable to this part |
| Pedal Included | No |
| Pedal Length (from Pivot) | Not applicable to this part |
| Pedal Length (Overall) | Not applicable to this part |
| Pedal Material | Not applicable to this part |
| Pedal Offset | Not applicable to this part |
| Pedal Pad Included | Not applicable to this part |
| Pedal Style | Not applicable to this part |
| Plunger Material | Not applicable to this part |
| Port Configuration | Side / Rear |
| Regulatory Compliance | FMVSS 121 |
| Rubber Boot Included | No |
| Supply (11) Port 1 | Cored Closed |
| Supply (11) Port 2 | 1/4-18 NPT |
| Supply (11) Port 3 | Open Port |
| Supply (12) Port 1 | Cored Closed |
| Supply (12) Port 2 | 1/4-18 NPT |
| Supply (12) Port 3 | Open Port |
| Supply (12) Port 4 | 1/8-27 NPT |
| Total Pedal Travel | Not applicable to this part |
| Waterproof | No |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 07894294759477 |
| VMRS Code | 013010051 |
BENDIX 800970 Cross References
| Brand | Part Number |
|---|---|
| BW800970 | |
| N/A | 289352N |
