MONROE 5622 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5622 Specifications
Product Attributes
| Lower Mount Code | SPEC |
| Upper Mount Code | S1 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Body Diameter | 1.75 IN |
| Compressed Length | 13.389 IN |
| Extended Length | 21.342 in |
| Gas Charged | Yes |
| Lower Mount Type | Clevis |
| Parts Pack(s) | P00906 |
| Travel Length | 7.953 in |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Compressed Length | 340.1 MM |
| Extended Length | 542.1 MM |
| Travel Length | 202 MM |
| Lower Mount Type | Special Mount |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Body Diameter | 44.4 MM |
| Lower Mount Code | SPEC |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Upper Mount Code | S1 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598039903 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5622 Cross References
| Brand | Part Number |
|---|---|
| 5622ST, GAMZ2V553BGRM1 | |
| AUTOZONE | TS32-30222B |
| AutoZone | TS3230222B |
| Duralast | TS3230222B |
| FCS | 341715 |
| FCS AUTO PARTS | 341715 |
| GABRIEL | 70037 |
| Hyundai | 546512H100, 546512H200, 546512L200, 546612H100, 546612H200, 546612L200, 553112H100, 553112H200, 553112L500 |
| KYB | 349085, 349084 |
| KYB AMERICA LLC. | 349085 |
| MasterPro Shocks and Struts | HY105 |
| Monroe Shocks & Struts | 210064 |
| NAPA Shocks | 5622, NS5622 |
| OEM | 553112H100 |
| SENSEN | 32130331 |
| Top Quality | 785622 |
| UNITY AUTOMOTIVE | 259890, 2-259890-001, 4-11133-259890-001 |
MONROE 5622 Fits Vehicles
- Hyundai Elantra (2007-2010)
