MONROE 34945 Gas-Magnum Amortiguador

★★★★★ (0)
Monroe 34945 Suspension Shock Absorber Gas-Magnum Amortiguador
MONROE
Tap to view 3 more

MSRP: $72.19

$42.49

Save $29.70

Limited availability at this price!

In Stock

Get as soon as Monday, Nov 30
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

MONROE 34945 Part Description

Manufacturer

MONROE

Product Description

Gas-Magnum Front Suspension Shock Absorber

Features & Benefits

  • DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
  • BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
  • CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
  • BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee

MONROE 34945 Specifications

Product Attributes

Compressed Length8.9375 IN
Compressed Length227 MM
Extended Length13.375 in
Extended Length339.7 MM
Travel Length4.437 in
Travel Length112.7 MM
Lower Mount TypeCross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.1/2" Pin Length (Hole Center to Center)
Lower Mount TypeT-Bar
Lower Mount CodeXP5
Upper Mount TypeStem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
Upper Mount CodeS4
Shock Absorber Rod End Measuring PointBase of Stem
Shock Absorber Body End Measuring PointCenter of Mounting Hole
Gas ChargedYes
Mounting Hardware IncludedYes
Parts Pack(s)P1134
Dust Shield IncludedNo
Includes Bump StopNo
Internal Rebound BumperNo
Hydraulic LockoutNo
Grade TypePremium
Active or Passive SuspensionPassive
Adjustable CompressionNo
Adjustable ReboundNo
Adjustable Ride HeightNo
Part DescriptionShock Absorber

Additional Information

MSDS Sheet Number01170
Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708803000
Harmonized Tariff Code (Schedule B)8708800050
Harmonized Tariff Code (HTS)8708801600
UPC00048598074300
VMRS Code016008003
UNSPSC25172011

MONROE 34945 Cross References

BrandPart Number
34945MM, FT4Z5813300BA
Chevrolet22046811, 22064063, 22064065
FCS342799
FCS Auto Parts342799
GABRIEL81750, 58421, 61504
GMC22064063
General Motors22064063
KYB344040, 565046, KG5450
NAPA Shocks76945
Sensen12130611

MONROE 34945 Fits Vehicles

  • Chevrolet LLV (1987-1995)
