(888) 312-8812 Login SignupMONROE 37424 OESpectrum Suspension Shock Absorber
Tap to view 5 more
$6699
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 18
MONROE 37424 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
OESpectrum Suspension Shock Absorber
MONROE 37424 Specifications
Product Attributes
| Lower Mount Code | LS78 |
| Upper Mount Code | S34 |
| Compressed Bumper Stop | No |
| Dust Shield | No |
| Extended Bumper Stop | Yes |
| Extended Hydraulic Lockout | No |
| Body Diameter | 1.75 IN |
| Compressed Length | 12.63 IN |
| Extended Length | 18.25 in |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1 1/2" Sleeve OAL |
| Parts Pack(s) | P01603 |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Travel Length | 5.62 in |
| Upper Mount Type | Stem Mount - 2 1/4" Stem Length X 3/8"-24 Thread Pitch |
| Compressed Length | 320.8 MM |
| Extended Length | 463.5 MM |
| Travel Length | 142.7 MM |
| Body Diameter | 44.4 MM |
| Dust Shield Included | No |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS78 |
| Upper Mount Code | S34 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598247513 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 37424 Cross References
| Brand | Part Number |
|---|---|
| Autopart International | 2701719354 |
| Chrysler | 68521556AA |
| FCS | 346562 |
| Monroe Shocks & Struts | 210365 |
| NAPA Shocks | 37424 |
MONROE 37424 Fits Vehicles
- Chrysler Pacifica (2020-2025)
MONROE 37424 Customer Reviews
No reviews yet
Be the first to review this product!
MONROE 37424 Manufacturer Information
Monroe products are built for the road ahead. Since its founding in 1916, Monroe® has been known for its world-class solutions that are precision-engineered and meticulously tested with the specific vehicle's ride and handling profile in mind. As the leading supplier of Original Equipment ride control products to global automotive manufacturers, Monroe helped establish the benchmarks of handling and ride excellence in every stage of a vehicle's life. Whether you're upgrading your truck, converting its suspension, or restoring its original state, Monroe has got you covered. It offers the best-in-class shocks, strut assemblies, steering stabilizers, conversion kits, lift support, and many other suspension components that will help enhance your safety and driving experience.
MONROE 37424 Questions & Answers
No questions yet
Be the first to ask a question about this product!
