(888) 312-8812 Login SignupRAYBESTOS 680680 Raybestos Specialty - Truck Brake Rotor
MSRP: $300.18
$22599
Save $74.19
Limited availability at this price!
In Stock
Get it by Friday, Jul 24
RAYBESTOS 680680 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2023-2021,2019-2008 Ford E-350 Super Duty Rear, 2014-2010 Ford Econoline Van Rear, 2014-2010 Ford Econoline Wagon Rear
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 680680 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 4.854 IN |
| Center Hole Diameter | 123.3 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.35 IN |
| Discard Thickness | 34.3 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.7 IN |
| Mounting Bolt Hole Circle Diameter | 144.8 MM |
| Nominal Thickness | 1.42 IN |
| Nominal Thickness | 36.05 MM |
| Outside Diameter | 13.583 IN |
| Outside Diameter | 345 MM |
| Overall Height | 4.213 IN |
| Overall Height | 107 MM |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352656907 |
RAYBESTOS 680680 Cross References
| Brand | Part Number |
|---|---|
| DFP22350, 829352656907 | |
| ADVANCE AUTO PARTS | YH246573, YH246573C, YH246573P |
| AUTOXTRA | AX900690 |
| AUTOZONE | 42263, 42263DG |
| BENDIX | PRT5914 |
| BOSCH | 20011508 |
| BRAKEBEST | 20011508, 680680, 680680FZN, 680680R, 680680RGS |
| BrakeBest | 680681RGS |
| Brembo | 09.E287.11 |
| CENTRIC | 120.65125, 120.65125CRY, 121.65125, 320.65125F |
| Casting Numbers | 326432 |
| Centric Parts | 120.65125, 120.65125CRY, 121.65125, 320.65125F |
| DURA CORP | BR54163, BR900690 |
| DuraGo | 900690, BR900690, BR900690-02 |
| FORD | 8C2Z2C026A |
| MAGMA PRODUCTS | PSR205233 |
| MONROE BRAKES | BD126465 |
| NEOTEK | 1071081GF |
| NEWTEK AUTOMOTIVE | 54163 |
| Newtek Automotive USA | 54163 |
| PROMAX | 14-54163 |
| PRONTO | BR900690 |
| Qualis | 42263 |
| TopNotch | TN680680GEO |
| UAP | 680680 |
| WAGNER | BD126465E, BD126465 |
| WAGNER BRAKE | BD126465 |
| WINHERE | 6621159 |
| WORLDPAC | 1407-246573, 1427-732032 |
| Wagner Brake | BD126465E |
RAYBESTOS 680680 Fits Vehicles
- Ford Econoline Van (2010-2014)
- Ford Econoline Wagon (2010-2014)
- Ford E-350 Super Duty (2008-2019, 2021-2023)
