(888) 312-8812 Login SignupCENTRIC 320.65125F Centric GCX Rotor with Full Coating
Tap to view 4 more
$12349
Limited availability at this price!
1 Day Lead Time
Get it by Tuesday, Jul 28
CENTRIC 320.65125F Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.65125F Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Kgs | 15.550 |
| Max Pb Drum Dia [cntrc] In | 8.984 |
| Misc Holes [cntrc] | 0 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 34.200 |
| Vane Style [cntrc] | Straight |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 228.200 |
| Discard Thickness | 1.354 IN |
| Discard Thickness | 34.400 MM |
| Nominal Thickness | 36.000 MM |
| Nominal Thickness | 1.417 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 107.000 MM |
| Overall Height | 4.213 IN |
| Outside Diameter | 13.583 IN |
| Outside Diameter | 345.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 226.000 MM |
| Nominal Drum Diameter | 8.898 IN |
| Bearings Included | No |
| Center Hole Diameter | 4.854 IN |
| Center Hole Diameter | 123.300 MM |
| Mounting Bolt Hole Circle Diameter | 145.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.709 IN |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 13.000 MM |
| Stud/Lug Hole Diameter | 0.512 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590393132 |
CENTRIC 320.65125F Cross References
CENTRIC 320.65125F Fits Vehicles
- Ford E-350 Super Duty (2008-2019, 2021-2023)
