(888) 312-8812 Login SignupRAYBESTOS 980069 Raybestos Specialty - Street Performance Brake Rotor
$71.33
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980069 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2004-2002 Acura RL Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980069 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.526 IN |
| Center Hole Diameter | 64.15 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 114.3 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12 MM |
| Outside Diameter | 11.09 IN |
| Outside Diameter | 281.7 MM |
| Overall Height | 2.41 IN |
| Overall Height | 61.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00753497928868 |
RAYBESTOS 980069 Cross References
| Brand | Part Number |
|---|---|
| 77416944, 753497928868 | |
| ADVANCE AUTO PARTS | YH145361, YH145361C |
| AUTOZONE | 31303, 31303DG |
| BENDIX | 145361 |
| BOSCH | 26010775 |
| BRAKEBEST | 26010775, 980069, 980069R, 980069RGS, BD126018 |
| BREMBO | 08.6898.85, 25656 |
| CENTRIC | 120.40054, 121.40054, 126.40054CSL, 126.40054CSR, 126.40054SL, 126.40054SR, 127.40054L, 127.40054R, 128.40054L, 128.40054R |
| CONTINENTAL-CONTITECH | CW12709 |
| Casting Numbers | 211266-C, 325973 |
| Centric Parts | 120.40054, 121.40054, 126.40054CSL, 126.40054CSR, 126.40054SL, 126.40054SR, 127.40054L, 127.40054R, 128.40054L, 128.40054R |
| DURA CORP | BR31303 |
| DuraGo | BR31303 |
| HONDA | 42510SZ3N00 |
| MIGHTY DISTRIBUTING SYSTEM | 31303 |
| NEWTEK AUTOMOTIVE | 31303 |
| Newtek Automotive USA | 31303 |
| PROMAX | 14-31303 |
| PRONTO | BR31303 |
| QUALIS | 31303 |
| QUALITY BRAND | 31303 |
| STANDARD ROTORS AND DRUMS | 31303 |
| UAP | 31303 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51416 |
| WAGNER | BD126018 |
| WAGNER BRAKE | BD126018 |
| WINHERE | 441520 |
RAYBESTOS 980069 Fits Vehicles
- Acura RL (2002-2004)
