(888) 312-8812 Login SignupRAYBESTOS 66840 Raybestos Specialty - Street Performance Brake Rotor
$6149
Limited availability at this price!
1 Day Lead Time
Get it by Tuesday, Sep 1
RAYBESTOS 66840 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2005-2002 Ford Thunderbird Rear, 2006-2000 Lincoln LS Rear, 2005-2000 Jaguar S-Type Rear, 2006-2004 Jaguar XJ8 Rear, 2006-2004 Jaguar Vanden Plas Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 66840 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.54 IN |
| Center Hole Diameter | 64.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.728 IN |
| Discard Thickness | 18.5 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.25 IN |
| Mounting Bolt Hole Circle Diameter | 107.95 MM |
| Mounting Bolt Hole Diameter | 0.557 IN |
| Mounting Bolt Hole Diameter | 14.15 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.79 IN |
| Nominal Thickness | 20.05 MM |
| Outside Diameter | 11.335 IN |
| Outside Diameter | 287.9 MM |
| Overall Height | 1.275 IN |
| Overall Height | 32.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730618326 |
RAYBESTOS 66840 Cross References
| Brand | Part Number |
|---|---|
| 74221083, 747730618326 | |
| ADVANCE AUTO PARTS | 145269, YH145269, YH145269C, YH145269P |
| AMERICAN REMANUFACTURED | 89-34062 |
| ATE BRAKE PRODUCTS | 420708, SP20708 |
| AUSTIN HEALY | JLM20802 |
| AUTOSPECIALTY | AR8162, AR8162E |
| AUTOXTRA | 125724, AX54089 |
| AUTOZONE | 54089, 54089DG, DL54089 |
| BECK/ARNLEY | 083-2808 |
| BENDIX | 145269 |
| BRAKEBEST | 20010378, 66840, 66840FZN, 66840R, 66840RGS, 81-125724, BD125724 |
| BREMBO | 25526 |
| Brembo | 09.7911.21 |
| CENTRIC | 120.61062, 121.61062, 125.61062, 125.61062CRY, 126.61062CSL, 126.61062CSR, 126.61062SL, 126.61062SR, 127.61062L, 127.61062R, 128.61062CL, 128.61062CR, 128.61062L, 128.61062R, 320.61062, 320.61062H |
| CONTINENTAL-CONTITECH | CW20708 |
| Casting Numbers | 1R832C026AA, 211258-C, 325507 |
| Centric Parts | 120.61062, 121.61062, 125.61062, 125.61062CRY, 126.61062CSL, 126.61062CSR, 126.61062SL, 126.61062SR, 127.61062L, 127.61062R, 128.61062CL, 128.61062CR, 128.61062L, 128.61062R, 320.61062, 320.61062H, 320.61062F |
| DURA CORP | BR54089 |
| DuraGo | BR54089 |
| FORD | 1R8Z2C026AA, XW4Z2C026AA |
| JAGUAR | JLM20802, XR827087 |
| MAGMA PRODUCTS | PSR203063 |
| MIGHTY DISTRIBUTING SYSTEM | 54089 |
| MOTORCRAFT | BRR105 |
| Motorcraft | NBRR114 |
| N/A | JLM20802 |
| NAPA BRAKES | SDK6214 |
| NEOTEK | 107194GF |
| NEWTEK AUTOMOTIVE | 54089 |
| Newtek Automotive USA | 54089 |
| PEP BOYS | 54089G |
| POWERSTOP | AR8162EVC |
| PROMAX | 14-54089 |
| PRONTO | BR54089 |
| QUALIS | 54089 |
| QUALITY BRAND | 54089 |
| QUINTON HAZELL | BDC5225 |
| STANDARD ROTORS AND DRUMS | 54089 |
| THE UNIVERSAL GROUP | 102928 |
| TRW | 4106 |
| UAP | 54089 |
| Universal | 102928 |
| VAICO | V5480001 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51305 |
| WABCO | PS125724 |
| WABCO - Archived | PS125724 |
| WAGNER | BD125724 |
| WAGNER BRAKE | BD125724 |
| WINHERE | 662654, YH2654 |
| WORLDPAC | 1407-25696 |
RAYBESTOS 66840 Fits Vehicles
- Jaguar XJR (2003)
- Jaguar XJ8 (2003-2006)
- Jaguar Vanden Plas (2004-2006)
- Lincoln LS (2000-2006)
- Ford Thunderbird (2002-2005)
- Jaguar S-Type (2000-2005)
