BENDIX 802191 Part Description
Manufacturer
Product Description
Air Dryer
Features & Benefits
- Four parallel pressure-protection valves manage multiple downstream air circuits
- Employs a standard M39 x 1.5-6H right-hand cartridge thread
- Governor cycles compressor control between 110 psi and 130 psi
- Opens protected delivery circuits at the 106 psi threshold
Bendix Air Brake Dryer
Some charging systems ask the dryer to do more than remove moisture, and the Bendix Air Brake Dryer answers that need with an AD-IS style assembly that also manages pressure distribution. Its M39 x 1.5-6H right-hand cartridge works with 110 psi cut-in and 130 psi cut-out governor settings. That integrated pressure behavior makes circuit arrangement and settings just as important as cartridge fit when the unit is matched to the existing charging system. As pressure builds, the Bendix 802191 begins opening its primary, secondary, and auxiliary delivery circuits at 106 psi through four parallel pressure-protection valves.
BENDIX 802191 Specifications
Product Attributes
| Air Dryer Type | Stand-Alone |
| AUX 1 Delivery Opening Pressure | 106 PSI |
| AUX 1 Delivery Port 1 | 1/4-18 NPT |
| AUX 1 Delivery Port 2 | 1/4-18 NPT |
| AUX 1 Delivery Port 3 | 1/4-18 NPT |
| AUX 1 Delivery Port 4 | 1/4-18 NPT |
| AUX 2 Delivery Opening Pressure | 106 PSI |
| AUX 2 Delivery Port | 1/4-18 NPT |
| Cartridge Thread | M39 x 1.5-6H RH |
| Cartridge Type | Standard |
| Cautionary Note(s) | Pressure protection valve configs are not interchangeable. |
| Clearance to Remove Cartridge | 1.00 IN |
| Compressor Unloader Port | Not applicable to this part |
| Cut-In Pressure | 110 PSI |
| Cut-Out Pressure | 130 PSI |
| Governor Included | Yes |
| Governor Reservoir Port | 1/8-27 NPT (Plugged) |
| Governor Type | Non-Adjustable |
| Governor Unloader Port | 3/8 PTC (Straight) |
| Heater / Thermostat Rating | 12V / 90W |
| Heater Connector Color | White |
| Heater Connector Type | Metri-Pack 280 Series 2-Way Sealed Connector (Male) |
| Market Indicator | Aftermarket New |
| Maximum Inlet Temperature | 160 AdegF (71 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting | Mount to Purge Reservoir (Not Included) |
| Number of Compartments | Not applicable to this part |
| Pressure Protection Valve Configuration | 4 in Parallel |
| Pressure Range | Not applicable to this part |
| PRI Delivery Opening Pressure | 106 PSI |
| PRI Delivery Port 21 | 1/4-18 NPT |
| Purge Exhaust Port | Standard |
| Purge Valve Type | Hard Seat |
| Purge Volume | Not applicable to this part |
| Remote Charge / Fill Port (through Desiccant) | Not applicable to this part |
| Remote Charge / Fill Port 1 (after Desiccant) | Not applicable to this part |
| Remote Charge / Fill Port 2 (after Desiccant) | Not applicable to this part |
| Reservoir Diameter | Not applicable to this part |
| Reservoir Fill Type | Not applicable to this part |
| Reservoir Length | Not applicable to this part |
| Reservoir Material | Not applicable to this part |
| Safety Valve Opening Pressure | 153 PSI |
| SEC Delivery Opening Pressure | 106 PSI |
| SEC Delivery Port 22 | 1/4-18 NPT |
| Supply Port | 1/2-14 NPT |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 07894294739479 |
| VMRS Code | 013010252 |
BENDIX 802191 Cross References
| Brand | Part Number |
|---|---|
| BW802191 | |
| N/A | 109495 |
