(888) 312-8812 Login SignupBENDIX NT3030STD-78 Spring Brake (S-Cam)
Tap to view 5 more
MSRP: $164.88
$7649
Save $88.39
Limited availability at this price!
In Stock
Get as soon as Tuesday, Oct 13
BENDIX NT3030STD-78 Part Description
Manufacturer
Product Description
Spring Brake (S-Cam)
Features & Benefits
- Cage bolts secure the spring under full compression safely
- Splits service braking and parking function into separate sections
- Contains full spring force safely without cage failure
- Chamber size matches the axle's designed spring configuration
Bendix Spring Brake
Restore fail-safe parking and emergency braking with the Bendix Spring Brake, pairing a service chamber with a spring-actuated section in one housing. The spring section applies the brakes mechanically the moment air pressure releases, whether from setting the parking brake or an emergency air loss, while the service section handles normal stops. The Bendix NT3030STD-78 matches the chamber size and spring configuration this axle uses, so service stroke and spring force stay within their designed range. A fresh spring brake restores both functions, so the vehicle isn't left without a working parking brake.
BENDIX NT3030STD-78 Specifications
Product Attributes
| Brand | EnduraSure |
| Cautionary Note(s) | Do not disassemble while park side is caged under pressure |
| Chamber Style | Double Diaphragm |
| Chamber Type / Size | T30/30 |
| Clamp Angle | 45Adeg |
| Clevis / Yoke Arm Bushing Pin Diameter | Not applicable to this part |
| Clevis / Yoke Arm Link Pin Diameter | Not applicable to this part |
| Clevis / Yoke Pin Spacing | Not applicable to this part |
| Clevis / Yoke Style | Not Included |
| Market Indicator | Aftermarket New |
| Maximum Operating Temperature | 175 AdegF (79 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting Stud Length | 1.50 IN (38.1 MM) |
| Parking Port (12) | 3/8-18 NPTF |
| Port Angle | 270Adeg |
| Push Rod Length (to Yoke Pin Center when Applicable) [IN] | 7.80 in |
| Push Rod Thread / Style | 5/8-18 UNF-2A |
| Service Chamber Joint Type | Double Clamp Band |
| Service Port (11) | 3/8-18 NPTF |
| Stroke | 2.50 IN (63.5 MM) |
| Stud Spacing | 4.75 IN (120.7 MM) |
| Stud Thread Size | 5/8-11 UNC-2A |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 07894294759002 |
| VMRS Code | 013004027 |
BENDIX NT3030STD-78 Cross References
| Brand | Part Number |
|---|---|
| BENNT3030STD-78, BWNT3030STD78 | |
| HALDEX | GC3030 |
| N/A | 800921 |
