Centric 122.62039 - Centric Premium Brake Drum
$8899
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
Product Attributes
| Weight [cntrc] Kgs | 5.591 |
| Weight [cntrc] Lbs | 12.300 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 110.000 |
| Bolt Circle Diameter [cntrc] In | 4.331 |
| Hub Hole / Register [cntrc] Mm | 65.500 |
| Hub Hole / Register [cntrc] In | 2.579 |
| Height [cntrc] Mm | 71.628 |
| Height [cntrc] In | 2.820 |
| Friction Surface Width [cntrc] Mm | 50.700 |
| Friction Surface Width [cntrc] In | 1.996 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 230.600 MM |
| Maximum Brake Diameter (Discard) | 9.079 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 274.600 MM |
| Outside Diameter | 10.811 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.000 MM |
| Mounting Hole Diameter | 0.551 IN |
| Nominal Drum Diameter | 228.600 MM |
| Nominal Drum Diameter | 9.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890592136 |
Part Interchanges
CENTRIC 122.62039 Cross Reference
We have 3 alternatives for the 122.62039 by CENTRIC:
Fits Vehicles
- Chevrolet Cobalt (2009-2010)
- Pontiac G5 (2009-2010)
- Chevrolet HHR (2009-2011)
