Centric 123.42025 - C-Tek Standard Brake Drum
$6549
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 8.182 |
| Weight [cntrc] Lbs | 18.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 100.500 |
| Hub Hole / Register [cntrc] In | 3.957 |
| Height [cntrc] Mm | 74.100 |
| Height [cntrc] In | 2.917 |
| Friction Surface Width [cntrc] Mm | 62.500 |
| Friction Surface Width [cntrc] In | 2.461 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 261.500 MM |
| Maximum Brake Diameter (Discard) | 10.295 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 300.000 MM |
| Outside Diameter | 11.811 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.700 MM |
| Mounting Hole Diameter | 0.500 IN |
| Nominal Drum Diameter | 260.000 MM |
| Nominal Drum Diameter | 10.236 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890305071 |
Part Interchanges
CENTRIC 123.42025 Cross Reference
We have 3 alternatives for the 123.42025 by CENTRIC:
Fits Vehicles
- Nissan NP300 Frontier (2016-2017)
- Nissan NV350 Urvan (2014-2017)
- Nissan NP300 (2009-2015, 2017-2018)
- Nissan Urvan (2000-2013)
- Nissan 720 (1985-1986)
- Nissan Pickup (1995-1998, 2000-2004)
- Nissan Pathfinder (1988-1995)
- Nissan Frontier (1998-2004)
- Nissan D21 (1986-1994)
