CENTRIC 123.40007 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.40007 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 3.409 |
| Weight [cntrc] Lbs | 7.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 61.000 |
| Hub Hole / Register [cntrc] In | 2.402 |
| Height [cntrc] Mm | 61.500 |
| Height [cntrc] In | 2.421 |
| Friction Surface Width [cntrc] Mm | 38.000 |
| Friction Surface Width [cntrc] In | 1.496 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 181.000 MM |
| Maximum Brake Diameter (Discard) | 7.126 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 217.000 MM |
| Outside Diameter | 8.543 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.750 MM |
| Mounting Hole Diameter | 0.502 IN |
| Nominal Drum Diameter | 180.000 MM |
| Nominal Drum Diameter | 7.087 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890051602 |
CENTRIC 123.40007 Cross References
| Brand | Part Number |
|---|---|
| 9505, 9392, 9506DGS, 109506, 9506, 52-60764, 5260764, BD60764 | |
| N/A | BD60764, BD60849, 52-60764, 5260764, 0832110, 0832558, 3507, 35077, BD3507, 63 72 150, 6372150, 42610SB2010, 35077G, 3507G, 116221, 467, 46210SB2010, 100356, 42610SB2000, 42610SB2661, 42610SB2662, 42610SB2760, 42610SB2761, 140651, 140474, PDR0474, PDR0651, 208070, 6401544, 6401551, 440-1551, 4401551, 643, JBD124, JBD124E, D9339, 87392, 87505, 87506, 1408-15837, 21057, X21720, BD1484, 9392, 9505, 9506, 9506DGS, 9506R, 109506, 9505DGS, DB4062, 78-08007, 7808007, 8808007, 78808007, 63260, 36559007 |
| PRONTO | BD3507 |
| RAYBESTOS | 9505, 9505R, 9506, 9506R |
| WAGNER | BD60764 |
CENTRIC 123.40007 Fits Vehicles
- Honda CRX (1988-1991)
- Honda Civic del Sol (1993-1997)
- Honda Civic (1984-1995)
