CENTRIC 123.33006 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.33006 Specifications
Product Attributes
| Weight [cntrc] Kgs | 6.477 |
| Weight [cntrc] Lbs | 14.250 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 130.000 |
| Bolt Circle Diameter [cntrc] In | 5.118 |
| Stud Thread Pitch [cntrc] Mm | 1.50 |
| Hub Hole / Register [cntrc] Mm | 64.800 |
| Hub Hole / Register [cntrc] In | 2.551 |
| Height [cntrc] Mm | 89.300 |
| Height [cntrc] In | 3.516 |
| Friction Surface Width [cntrc] Mm | 53.000 |
| Friction Surface Width [cntrc] In | 2.087 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 249.000 MM |
| Maximum Brake Diameter (Discard) | 9.803 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 279.000 MM |
| Outside Diameter | 10.984 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.000 MM |
| Nominal Drum Diameter | 248.100 MM |
| Nominal Drum Diameter | 9.768 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890051565 |
CENTRIC 123.33006 Cross References
| Brand | Part Number |
|---|---|
| 122.33006, F1EZ14632AD | |
| N/A | BD97067, 3818, BD3818, 123.33006, 6316040, 63 16 040, 3818G, 113405615B, 113405615D, 113405615H, 100604, 217180, 140355, 6401268, 675, EBD010E, D9142, 87368, X30734, 21021, BD1291, 9368, 9368R, 9368DGS, 78894004, 36574006 |
| PRONTO | BD3818 |
| RAYBESTOS | 9368, 9368R |
| WAGNER | BD97067 |
CENTRIC 123.33006 Fits Vehicles
- Volkswagen Brasilia (1975-1982)
- Volkswagen Super Beetle (1971-1979)
